Micc302 Temperature Transmitter

Name: Micc302 Temperature Transmitter
Brand: all-electronics-online.com
SKU: 809337225
Availability: InStock
Rating: 4.6 (25 reviews)

Price:	Negotiable/Piece
Min Order:	100/Piece
Pay Type:	L/C,T/T,Western Union,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	MICC302

Product Description

Properties

Basic parameter			Input

Voltage supply		12~45VDC.	Measured		Temeprature
Voltage supply		12~45VDC.	variable		Temeprature
			variable
Power protection		Reverse polarity	Accuracy		0.2%
Power protection		protection			0.2%
		protection
Damping time		< 5S	Sensor type and		Refer to the following
Dielectric			measuring range		Input type and range
strength(power		1500V,AC,1min
supply	terminals	1500V,AC,1min	Output
between the shell)			Output
between the shell)
Insulation	resistance
(between	the power
supply terminal, the		≥100MΩ	Current output		4~20mA
input terminal and the			Current output		4~20mA
input terminal and the
housing)
			Load		RL≤(Ue-12)/0.022A
			resistance		RL≤(Ue-12)/0.022A
		GB/T 17626.1-2006	resistance
Electromagnetic		GB/T 17626.1-2006	Upper and lower
Electromagnetic		GB/T 17626.2-2006	Upper and lower
compatibility		GB/T 17626.2-2006	limit	overflow
compatibility		GB/T 17626.4-2008	limit	overflow	IH = 22mA ; IL= 3.8mA
		GB/T 17626.4-2008	alarm	output
			alarm	output
			current
Mini range		50ºC	output	current of	22mA
Weight		46g	input break alarm		22mA

Input type and range

Sensor	Type	Range		Output
				accuracy

	Pt100	-200ºC~+850ºC		0.4ºC/0.2%	Configuration setting
	Cu50	ºC~	ºC	ºC
		-50	+150	0.4 /0.2%	Setting euqipment: handheld
(RTD)	Cu100	-50ºC~+150ºC		0.4ºC/0.2%
					communicator MICC300.
	Ni100	-100ºC~+260ºC		0.4ºC/0.2%


	Ni120	-60ºC~+200ºC		0.4ºC/0.2%
	T	-200ºC~+400ºC		1ºC/0.2%
	E	-200ºC~		1ºC/0.2%
		+1000ºC

	J	-200ºC~		1ºC/0.2%
		+1200ºC

	K	-200ºC~		1ºC/0.2%	Ambient temp condition
		+1370ºC
					Storage temp::-30ºC~+80ºC
(TC)		-200ºC~
	N			1ºC/0.2%	Working temp:-25ºC~+75ºC
		+1300ºC
					Relative humidity:≤85%
	R	0ºC~+1770ºC		2ºC/0.2%
					Standard temp:23ºC
	S	0ºC~+1770ºC		2ºC/0.2%
	B	0ºC~+1820ºC		2ºC/0.2%
	Millivolt	-10mV~70mV		40uV/0.2%
	Output

"Output Accuracy" take the bigger one of the
configuration scale errors.
★Reference condition: standard temp: 23ºC(73.4ºF)± 5ºC.
