Mimo Antenna 5150MHz~5850MHz Panel Antenna
| Product Name | 5.1~5.8GHz 23dbi panel antenna |
| Model | HYA-5158EPF23 |
Descriptions
| 5.1~5.8GHz panel antenna is high gain, low VSWR, broad bandwidth, strong non-corrosibility and compact size. It is applied to point-to-point or point-to-multipoint application, 5.1/5.5/5.8GHz WLAN system and 5.8GHz UNII/ISM system. |
| Electrical Specification |
| Frequency Range-MHz | 5150~5850 |
| Bandwidth-MHz | 700 |
| Gain-dBi | ≥23 |
| VSWR | ≤1.5 |
| Horizontal Beam width -° | 11 |
| Vertical Beam width-° | 11 |
| F/B Ratio-dB | ≥28 |
| Nominal Impedance-Ω | 50 |
| Polarization | Vertical or horizontal |
| Max. Power-W | 50 |
| Connector | N Female or customized |
| Mechanical Specification |
| Antenna Dimension-mm | 305×305×25 |
| Cavity Dimension-mm | 235×235×45 |
| Weight-kg | 2.8 |
| Pole dimension-mm | Ф40~50 |
| Temperature-ºC | -40~+60 |
| Humidity- | 5~95 |
APPLICATION AREA
