Mini Isolation MCB Circuit Breaker (CDSB5)

Name: Mini Isolation MCB Circuit Breaker (CDSB5)
Brand: all-electronics-online.com
SKU: 826634205
Availability: InStock
Rating: 4.8 (73 reviews)

Price:	US $ 1.12/Piece
Min Order:	10/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

switch miniature circuit breaker
Application
The product,used to protect line conductor and overload,and short circuit of small sealed motors,is mainly for protection of curcuit with AC220v and 50Hz/60Hz,and for infrequent conversion under normal conditions as well,its action can be as up to 22pole with leakage.
Specification:

Rated voltage;220v

Rated current:2,4,6,10,25,32a

Breaking capacity:3KA

Mechanical and electrical life:6000times

Width pole:P+N=& 18MM

Accodring to standands:IEC898-7
GB1096-89 BS3871

Weight(g)	1P	2P	3P	4P
Weight(g)	102	208	308	408

Product Details:

Website:www.maxwel.com

Prod Model:	CDSB5
Colour:	Grey
Primary Current:	5A~5000A
Class:	0.5/1.0
Frequency:	50/60Hz
Rated Voltage:	220V
Breaking Capacity:	Low Voltage Circuit Breakers
Speed:	Normal Type Circuit Breaker
Arc-extinguishing Medium:	Air
Installation:	Fixed
Structure:	MCB
Certification:	CE
