Mini USB 5pin B Type Plug Connector A450503

Name: Mini USB 5pin B Type Plug Connector A450503
Brand: all-electronics-online.com
SKU: 831029785
Availability: InStock
Rating: 4.5 (150 reviews)

Price:	US $ 0.1-1/Piece
Min Order:	5000/Piece
Pay Type:	T/T

Contact Supplier

Showroom Product Company Profile

SPECIFICATIONS

Features and benefits
Used in Mobile phone
0.8mm pitch 5 Pin

Physical
Material:
Contact :Copper alloy T=0.25mm
Shell : Copper alloy T=0.40mm
Housing : LCP UL94V-0 Color :Black
Top Cover :SPCC T=0.30
Lower Cover :SPCC T=0.30
Finish:
Contact:Gold plating on contact area.
Sn plated on solder tails, 50u" nickel under plated all over
shell :50u" Min. Nickel plated
Top Cover: 50u" Min. Nickel plated
Lower Cover:50u" Min Nickel Plated

Reference information
Designed In: millimeters
Packaging : tray tape or tape reel

Electrical
Voltage rating :30 V
Current rating:1A
Dielectric strength :100VAC For 1minute Min
Insulation resistance: 100 MEG OHM Min
Contact resistance:50 MILL.OHM Max

Mechanlcal
Insertion force : 35N Max
extraction force : 7N~20N
Durability:5000 times

Envlronment
Operating temperature :-20ºC~+40ºC
Storage temperature :-40ºC~+60ºC
Relative humidity :95% Max

Prod Model:	A450503-A-XX-T
