Ni Metal Foam Nickel 1.6mmx960mm

Name: Ni Metal Foam Nickel 1.6mmx960mm
Brand: all-electronics-online.com
SKU: 701418732
Availability: InStock
Rating: 4.6 (104 reviews)

Price:	US $ 5/Square Meter
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Square Meter
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

FOAM NICKEL (Ni)

Foam Nickel is a low density permeable material that has a very high porosity with typically 75-95% of the volume consisting of void spaces. Nickel Foam has a wide variety of applications in heat exchangers, energy absorption, flow diffusion, lightweight optics and is used as a filter material for gas and liquid.

Tankii supplies high quality nickel foam for rechargeable battery applications. Our plates have proven to be excellent electrode substrates for Ni-Cd and Ni-H rechargeable batteries and hydrogen storage units.

Nickel Foam for Battery Cathode Substrate (1000mm length x 300mm width x 1.6mm thickness)

Specifications:

Pecifications

Ni Foam product is composed by pure Nickel.
Thickness: 0.3-20mm
Density: 280g/m2~4000g/m2
PPI: 15~120
Width:50~960mm

Ni Foam product is composed by pure Nickel. Product shows excellent properties of corrosion resistance and hardness. Usefulness: (Various shapes can be produced)
1. Used as the base plate of positive electrode in Ni-MH / Ni-Cd battery.
2. Filtration materials of air / oil / smoke etc.
3. Porous electrode in Galvano-Chemistry Engineering.
4. Elimination of heat.
5. Amortization materials.
6. Noise-Absorbing and Vibration-Absorbing materials.
7. Electromagnetic shielding materials.
8. Catalyst carrier.
9. Precious metal recovery.

SPECIFICATION
ITEM	CONTINUOUS NICKEL FOAM	THICK NICKEL FOAM
THICKNESS	(0.3~2.5)±0.05mm	(2.6~12)±0.05mm
PPI	90~120	20~80
SURFACE DENSITY	(280~1800)±30g/M2	(400~3000)±30g/M2
TENSILE STRENGTH	(VERTICAL)≥130n/CM2 (HORIZONTAL)≥100n/CM2
ELONGATION	(VERTICAL)≥5% (HORIZONTAL)≥12%
POROSITY	≥96%	≥96%
WIDTH	(50~960)±0.5mm	(50~960)±0.5mm
SPLICE FREQUENCY	200m≤4 junction	largest length 1000mm
RATIO RESISTANCE	≤5X10-6	≤5X10-6

Package

Why Us:

Good quality control in production process, ISO9001:2008,SGS,BV approved.

Excellent quality and Competitive price, OEM is available.

Available in an extensive range of stock or custom size.

The whole process from material to finished products can be traced.

Our Service:

Your inquiry related to our product & price will be replied within 24hours.

Well-trained & experienced staff are to answer all your inquiries professional in English of course.

OEM is highly welcomed. We have strong R&D team here to help.

Good after-sale service offered, please get back if you got questio

Prod Model:	Nickel Foam
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Type Of Battery:	NiMH
Material:	Pure Nickel
Ppi:	15~120
Width:	50~960
Thickness:	0.3~20
MOQ:	1 Square Meter/Square Meters
Type:	Ni-MH Batteries
Usage:	Boat
Nominal Voltage:	48V
Discharge Rate:	High Discharge Rate
Shape:	Split-Shaped Battery
Rechargeable:	Chargeable
