Applications of infrared radiation heating emitters:
Can be used in almost all the industries where heating is needed: Printing and dyeing, food, electronic, medicine, spin, timbering, paper industry, auto, plastic, fitment, shoemaking, metal, heat treatment, packing mechanism.
Can be used to different heating object: Plastic, paper, paint, dope, dry goods, cardboard, PCB, leather, latex, oil, chinaware, glass, metal, food, vegetable, meat, air and water.
DESCRIPTION OF ONE TUBE INFRARED HEATING EMITTER:
Finish: White reflector covered half of quartz tube
Voltage: 220V
Power: 1000W
Diameter: 12mm
Length: 340mm
Ceramic cap: D2 type
To order you must inform us the following features:
- Diameter of the heating emitter
- Length of the heating emitter
- Wattage
- Voltage
- Termination type how you want the heater to be connected with the electricity (screws, cable, cap etc. )
- Special Features (holes etc. )
It would be better for our understand If you could send us a drawing with all the characteristics noted.
Dandy-Link is a science-technology-oriented, quality-oriented and service-oriented company, specialized in designing, developing and producing IR quartz heaters that others can not be compared with:
1. More match IR spectrums: IR radiation heaters from Nanjing Dandy-Link Technology Co., Ltd cover the whole IR range. By choosing the correct spectrum for you production can give you shorter heating time, higher production rate and more energy saving.
2. Higher thermal density output: High quality material and polished fabrication process give the power of a single IR quartz heater be ranged from couples of ten watts to couples of thousand watts. You have sufficient choose to meet any requirement.
3. More effective reflective layer saves energy: Dandy-Link heaters could be plated a gold or non-organic reflective layer to concentrate the radiation energy to the heating object; Higher heating efficiency and less energy consumsion.
4. Cleaner heating means: The IR quartz heaters are made from chosen clear quartz. You don't have to worry about surface corrosion and dropping off. It can ensure a clean heating environment and will not contaminate the working pieces.
5. Quick and accurate thermal control: The thermal inertia of IR quartz heaters from Nanjing Dandy-Link is very small and response the thermal control commands in few seconds. Not only you can get a precision temperature but also react in a short time; It saves much energy.
6. Fitting the geometry form and dimension you need: Nanjing Dandy-Link Technology Co., Ltd provides you IR heaters in various geometry forms, single-tube type, dual-tube type and other odd forms. Dimension ranges from a few cm to two meters. It fits your requirement!
7. Longer serving life: High quality material and special fabrication process gives their IR heater super long life. The hi-temp tubular IR heater serves about 3000 hours while the mid-temp and low-temp ones 5000 to 10000 hours.
8. Cost effective: Cost of high quality IR quartz heaters from Nanjing Dandy-Link meets your budget. Pick the cost effective IR heater from Dandy-Link and give up the non cost effective ones. Get away from the harassment of the low quality heaters and concentrate to improve your business.
We believe that our products will meet your requirements
--- for their reliable quality and reasonable price.
| Heated length | Total length | Power | Voltage | Reflector | Diameter | Ceramic cap |
| (mm) | (mm) | (W) | (V) | (mm) |
| 100-300 | 170-400 | 300-1500 | 110/115/120/127 | G/W/N | 10/12/14/15 | A1/C/D2/E/X |
| 200-400 | 270-500 | 500-2000 | 220/230/235/240 | G/W/N | 10/12/14/15 | A1/C/D2/E/X |
| 400-800 | 470-900 | 1500-3000 | 220/230/235/240 | G/W/N | 10/12/14/15 | A1/C/D2/E/X |
| 400-800 | 470-900 | 2500-4500 | 380/400/415 | G/W/N | 10/12/14/15 | A1/A2/C/D2/E/X |
| 700-1200 | 770-1300 | 1500-2500 | 220/230/235/240 | G/W/N | 10/12/14/15 | A1/A2/C/D2/E/X |
| 1200-2000 | 1270-2100 | 1500-2500 | 220/230/235/240 | G/W/N | 10/12/14/15 | A1/A2/C/D2/E/X |
Nanjing Dandy-Link Technology is a science & technology-oriented company that has been highly honored by the Government and Business Sector for our honest reputation for successive years. And we are invited in developing the newest GB/T 4654-2008 National Infrared Standards for non-metallic basic body infrared heater. The high-quality products and good services from Dandy-Link Technology have already built up its own brand reputation, it's also highly praised by many clients, and it's used to replace foreign brands. Our company's products have all passed the ISO9001 authentication, and are honored as "quality-credit guaranteed demonstration company" by the Light production quality guarantee centre for many years. Thereinto the infrared heating emitters were awarded as "reassurance brand" because they continuously passed the examines, and it was unfurled on the
andand some other press.
Dandy-Link is a science & technology-oriented, quality-oriented, and service-oriented company, specialized in designing, manufacturing and developing the following products:
1. IR radiation heating emitters: High output IR radiation heating emitter (quartz heater), carbon fiber heater and IR radiation heating emitter with gold reflective coating.
2. Temperature and power controllers: Thyristor trigger(Thyristor zero crossing controller, Phase shift controller), Trigger module, Thyristor main circuit unit, Integrated Thyristor modular AC power controller and temperature control system.
3. IR radiation drying equipments: Infrared heating oven, Automotive paint baker and matched heating equipment sets.
We possess our own development group and core technology of said products. Therefore we have advantages over other similar products in advance and in quality. Our company's heating and temperature control products have a high technique jump-off point and a high quality/price rate, and considered more from the users' view, so that the reputation in the clients has risen quickly.
High quality Combined with our business concept of "Customer-centric", you will enjoy our suit and price-reasonable production, advanced and mature technology, comprehensive and consummate service. We believe that we can satisfy your company, and we hope we can have the opportunity to serve your company.
Any inquiry is appreciated.
Dandy-Link Technology_we can do better!
Anything need, please contact Anna: +86 18936279957.
