Outside Lightning Counting Surge Protection
Product features
380V surge protection box
Lightning count instructions
Fast response & stable performance
Build-in temperature control, circuit breaking technology, high security performance
Display status of on and off
Applications
Lightning and over-voltage protection of power, telecommunication, transportation, residence, railway, petro-chemistry industries
Technical data
Model PBX-100/380
Nominal operating voltage Un 220/380VAC
Maximum continuous operating voltage Uc 385VAC
Nominal discharge current In (8/20μs) 50KA
Maximum discharge current Imax (8/20μs) 100KA
Protection level Up (8/20μs,20KA) ≤2.8KV
Response time Ta ≤25ns
Indication function Working indication, malfunction indication, lightning stroke counting, warning in voice or lights
Dimension 400*300*120mm
Weight 2.5-5kg
Protection mode L/N-PE,L-N-PE ,Single phase
Lightning counts 0-99
Index of protection IP40
Operating environment Temperature:-40-+85ºC humidity: ≤95%
Connecting lead sectional area 4~25mm ²
Related items PBX-40/380/3+N, PBX-120/380/4, PBX-60/380/4, PBX120/220-2
Functions
Lightning protection box is made up of surge protection device, circuit breaking device, lightning counter, indicator light, alarming module to protect devices from overvoltage and over current.
There are fault sound and light alarm, lightning strike counter, status display to correctly show the working status, alarm with sound and lights when failure occurs; Once surge protection devices is weakened or unplugged, or circuit breaking devices is in mal-function, sound and light alarm will react( or obvious mal-function display will come out).
Set up of surge protection device
Surge protection device is made up of Chinese famous brand components;
There is working status indicator or window indication, long distance central monitoring/alarming connector with the product
Once the product is in degradation or damage, it must be removed from the circuit so as not to influence the working status of devices
Product is simple in structure and easy in stallation
Five years warranty
Installation
There are four wall mounting terminals outside the case of lightning protection box
