Premium Type C HDMI Cable V1.4
| Price: |
US $ 1.2/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1000/Piece |
| Pay Type: |
L/C,T/T |
Premium HDMI cable Type A-C High Speed +Ethernet, Support 4k*2K 1080P, for portable DVS, cameras Game consoles to you HDTV With a ture HD Connections,
SPECIFICATIONS:
· 2× HDMI 19PIN, male connectors Type A To Type C
· Support 3D, Ethernet, Audiot return channel
· Chromium metal casing
· Gold plated connectors
· With nylon protection layer protect cable from abrasion
· Digital Transfers at rates up to 10.2Gbps+
· High purity Oxygen Free Copper conductor
· Cable: UL20276 AWG(1P+D+AL+MY)*5+4C+AEB
· All materials conform to RoHS, CE, FCC, ATC, UL, HDMI standard of Europe
. Compatible with all HDMI backward versions
FEATURES:
· A premium quality HDMI to HDMI cable is suitable for use in HDTV, Home Theater, DVD player, game consoles, Camera and other portable HDMI devices
· 24k gold-plated connector resists corrosion and ensures an optimum connection for maximum signal transfer
· High pure Oxygen Free Copper conductor for maximum conductivity and reliability
· High density triple shielding for maximum rejection of EMI and RFI
· Compatible with multiple audio formats from stereo to multi-channel sound.
· Transfer Digital Audio & Video signals at warp speed of 10.2 Gigabytes per second
ELECTRICAL:
· 100% Open&Short Test
· Voltage: DC300V 5M ohm/10ms
· Insulation Resistance: 10MΩ Min
· Contact Resistance: 2 ohm max
· Working Temperature: -25C-80C
http://www.weidanelectronics.com/products/?sort=3&id=11
| CERTIFICATE | CE, ROSH, REACH, HDMI |
| Prod Model: |
WD2-020 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Outer Diameter: |
6.0/7.3/8.5mm |
| HDMI Version: |
V1.3 or V1.4 |
| Guage Of Conductor: |
0-5meter: AWG30/5-10meter: Agw28/10-15meter: AWG26 |
| Ferrite Beads: |
Optional |
| Lead Time: |
20-30 Days |
| Type: |
Twisted Pair |
| Certification: |
RoHS, Ce, ISO9001, UL, HDMI, Atc, FCC |
| Connector: |
HDMI |
