Pressure Switch Control Air Compressor 4 Port Heavy Duty

Features:
- Pressure switch 26 APM 90-125 PSI with 4 way manifold.
- With an Unloader.
- With on/off lever and 4 way manifold.
- Easy to install and convenient to use.
- The 4 way manifold gives you the option of connecting 3 additional accessories to your application. For example, you could plug in a gauge, safety valve, or regulator into the 1/4" manifold connections. The UN-USED connection ports can be plugged.
- Notice: Ensure your electric motors amp rating is less than the Max amp current of the pressure switch.


Specification:
1. Pressure: 90-125 PSI (pressure setings are adjustable)
2. Max pressure: 175 PSI
3. Min on: 35 PSI
4. Differential: 30-40 PSI
5. Port: 4 ports 1/4"(NPT) 4 Port Female
6. Pole: 2 Pole Rating
7. AMP Rating: 26 APMS Single Phase or Three Phase, 110/230

Package Included:

1 X Air Compressor Pressure Switch

Note:
-The amperage should not be more than 26 amps, if you have a bigger load than 26 amps,you need to use a magnetic starter to protect the pressure switch.
