| Prod Model: |
V60 |
| Markets: |
South America,Mid East,Eastern Asia,Western Europe |
| Tracking Channel: |
220 |
| IP: |
67 |
Product Description
V60 GNSS RTK SYSTEM
V60 is a more compact-design and higher-performance GNSS RTK system, besides its rugged design to resist impact and vibration. V60 has industrial OLED display screen on its front control panel to show all information and status of the work. With the smart speaker inside the receiver, the DIY guiding voice can be customized in any language, even dialect! 1GB internal storage plus 8GB Micro SD card memory is standard, V60 supports up to extension of memory. V60 system is fully compatible with other GNSS RTK receivers from the world market. The static date can be saved directly in RINEX format.
Linux Operation System
ARM 9G20 400MHz CPU, embedded Linux OS to support faster data transmission.
Intelligent Operation
* Equipped with smart speaker guiding during the whole operation. Voice assistance can help you master V60 operation quickly. Language can be customized.
* Industrial LED display screen on its front control panel to show all information and status of the work.
* Many one-button operations make your work easily. Base setup by one button can choose base coordinate from base list automatically.
* Automatic recording system log makes receiver diagnosis easy.
RINEX Storage
The static data can be saved directly in RINEX format. The V60 is fully compatible with other brands' receivers.
Quick Upgrade
Just copy the updated firmware to the V60, then restart to finish the upgrade in a few seconds.
Multi Constellation Tracking
* 220 tracking channels.
* Supports GPS, GLONASS, GALILEO, BDS, SBAS.
* Built-in NGS Approved Antenna.
High Power Transceiver UHF Radio
* The transceiver UHF radio enables the working mode switchable between base and rover.
* 5 watts (Max.) HI-TARGET internal UHF radio and 2 watts (Max.)Pacific Crest micro XDL internal UHF radio are optional
* Pacific Crest TrimTalk© internal UHF radio is compatible with other RTK.
Seamlessly Operation in CORS System
* Built-in GPRS/GSM/3G module makes V60 work perfectly with network RTK positioning.
Long-life Battery
* Powered by 5000mAh Li-Ion battery.
* Static working time 13 - 15 hours
* RTK Rover(UHF/GPRS/3G) working time 10 - 12 hours
* RTK Base working time 8 - 10 hours
Rugged Design, IP67
* IP67 dust/water protection.
* Withstands 3 meters natural fall onto concrete.
* Rapidly track and perfectly avoid or lessen obstruction and multipath effect to ensure superior positioning capability.
MEASUREMENTS
* 220 Channels
* Advanced Pacific Crest Maxwell 6 Custom Survey GNSS Technology
* High precision multiple correlator for GNSS pseudo range measurements
* Unfiltered, unsmoothed pseudo range measurements data for low noise, low multipath error, low time domain correlation and high dynamic response
* Very low noise GNSS carrier phase measurements with <1 mm precision in a 1 Hz bandwidth
* Signal-to-Noise ratios reported in dB-Hz
* Proven Pacific Crest low elevation tracking technology
Satellite signals tracked simultaneously
GPS: Simultaneous L1C/A, L2C, L2E, L5
GLONASS: Simultaneous L1C/A, L1P, L2C/A (GLONASS M only), L2P
SBAS: Simultaneous L1 C/A, L5
Galileo: Simultaneous L1 BOC, E5A, E5B, E5AltBOC
BDS/Compass: B1, B2
QZSS: L1 C/A, L1 SAIF, L2C, L5
POSITIONING PERFORMANCE
Static and Fast Static GNSS surveying
Horizontal: 2.5mm+0.5ppm RMS
Vertical: 5mm+0.5ppm RMS
Post Processing Kinematic
(PPK / Stop & Go) GNSS surveying
Horizontal: 1cm+1ppm RMS
Vertical: 2.5cm+1ppm RMS
Initialization time: typically 10 minutes for base while 5 minutes for rover
Initialization reliability: typically > 99.9%
Real time Kinematic (RTK) surveying
Horizontal: 8mm+1ppm RMS
Vertical: 15mm+1ppm RMS
Initialization time: typically < 8 seconds
Initialization reliability: typically > 99.9%
Code Differential GNSS positioning
Horizontal: 25cm+1ppm RMS
Vertical: 50cm+1ppm RMS
SBAS: 0.50m Horizontal, 0.85m Vertical
HARDWARE
Physical
Dimensions (W x H): 18.20cm x 9.80cm (7.17 in x 3.86 in)
Weight: 1.25kg (2.76lb) without internal battery
Operating temperature: -45ºC to +65ºC (-49ºF to +149ºF)
Storage temperature: -55ºC to +85ºC (-67ºF to +185ºF)
Humidity: 100%, considering
Water/dustproof: IP67 dustproof, protected from temporary immersion to depth of 1m (3.28ft).
Shock and Vibration: Designed to survive a 3m (9.84ft) natural fall onto concrete.
Electrical
Power 6V to 28V DC external power input
Power consumption ≤3.5W
Automatic Switching between internal power and external power
Rechargeable, removable 7.4V, 5000mAh Lithium-Ion battery in internal battery compartment
Internal battery life
Static 13 - 15 hours
RTK Rover (UHF/GPRS/3G) 10 - 12 hours
RTK Base 8 - 10 hours
I/O interface
1 x Bluetooth
1 x standard USB2.0 port
1 x TNC UHF connector
2 x RS232 serial port
2 x DC power input (8-pin & 5-pin)
1 x Micro SD card port
COMMUNICATION AND DATA STORAGE
3G Communication
Fully integrated, fully sealed internal 3G, compatible with GPRS
Network RTK (via CORS) range 20-50km
HI-TARGET internal UHF radio (standard)
Frequency: 450~470MHz with 116 channels
Transmitting Power: 1W, 2W, 5W adjustable
Transmitting Speed: 9.6Kbps, 19.2Kbps
Working Range: 5km typical, 8~10km optimal
Pacific Crest internal UHF radio
Frequency: 403~473 MHz
Transmitting Power: 0.5W, 2W adjustable
Transmitting Speed: Up to 19.2Kbps
Support most of radio communication protocol
Working Range: 3~5km typical, 8~10km optimal
HI-TARGET External UHF radio (standard)
Frequency: 460 MHz with 116 channels
Transmitting Power: 5W, 10W, 20W, 30W adjustable
Transmitting Speed: Up to 19.2Kbps
Working Range: 8~10km typical, 15~20km optimal
Pacific Crest ADL Vantage Pro External UHF radio
Frequency: 390~430 MHz or 430~470 MHz
Transmitting Power: 4W to 35W adjustable
Transmitting Speed: Up to 19.2Kbps
Support most of radio communication protocol
Working Range: 8~10km typical, 15~20km optimal
Support other external communication device
For example, external GSM modem.
Data storage
1GB Internal storage+ 8GB Internal Micro SD Card memory (Support up to 32GB extension)
Record GNS and Rinex format simultaneously
Data formats
(1Hz positioning output, up to 50 Hz - depends on installed option)
CMR: sCMRx, CMR, CMR+ input and output
RTCM: RTCM 2.1, 2.2, 2.3, 3.0, 3.1, 3.2 input and output
Navigation outputs ASCII: NMEA-0183 GSV, AVR, RMC, HDT, VGK, VHD, ROT, GGK, GGA, GSA, ZDA, VTG, GST, PJT, PJK, BPQ, GLL, GRS, GBS
Navigation outputs Binary: GSOF
1 Pulse Per Second Output
