PVC Insulated Sheathed Copper Nm-B Flexible Flat Cable

Name: PVC Insulated Sheathed Copper Nm-B Flexible Flat Cable
Brand: all-electronics-online.com
SKU: 712356192
Availability: InStock
Rating: 4.5 (70 reviews)

Price:	US $ 0.2-1/Meter
Min Order:	1000/Meter
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	BVVB
Type:	Insulated
Conductor Type:	Solid
Application:	Underground
Conductor Material:	Copper
Insulation Material:	PVC
Certification:	RoHS
Brand:	Sansen

Product Description

PVC Insulated sheathed Building copper Wire BVVB flexible Flat Cable

Product Description:
Model:flat cable
Intruduction of the Electric Wire PVC Insulated Single Core H05V-U / H07V-U/ H07V-R wire:
1, The national certification of qualified manufacturers
2, Standard: GB 5023.1, IEC 60227/228, VDE
3, CE, RoHS, ISO ,SGS Certificate
4, Meet European standards and can be customized according to customer requirements
5, OEM, ODM cooperation
PVC Insulated&Sheathed Copper Wire BVVB Flexible Flat Cable
Applications:
H05V-U / H07V-U are harmonized PVC European single-conductor hook-up wires with a solid bare copper core. Ideal for the internal wiring of appliances, apparatus, switchboards and distributor boards or where a solid core is required. Suitable in dry rooms for fixed and flexible laying. May be used for exposed and embedded conduits. Found in electronic and electrical equipment and switchgear cabinets designed for export to a European country for MRO replacement of European made equipment wire.
The products is suitable for use in power installations, fixed wiring or flexible connections for electrical appliances, Like lighting, electronic equipment, instrument and communication equipment with rated voltage 300/500V, 450/750V, The Operating temperature: Allowing the wire of work for long time should not exceed +70 centigrade.
Synthetic data of 300/500V BVVB model PVC insulated round cable with copper core and PVC sheath

Nominal cross section of conductor mm²	Minimum number of single line in the stranded conductor	Rated value of insulator thickness mm	Rated value of sheath thickness mm	Upper value of average overall diameter mm	Minimum insulation resistance under temperature 70⁰C MΩ.km

2×0.75 2×1.0 2×1.5 2×2.5 2×4 2×4 2×6 2×6 2×10 3×0.75 3×1.0 3×1.5 3×2.5 3×4 3×4 3×6 3×6 3×10	1 1 1 1 1 7 1 7 7 1 1 1 1 1 7 1 7 7	0.6 0.6 0.7 0.8 0.8 0.8 0.8 0.8 1.0 0.6 0.6 0.7 0.8 0.8 0.8 0.8 0.8 1.0	0.9 0.9 0.9 1.0 1.0 1.0 1.1 1.1 1.2 0.9 0.9 0.9 1.0 1.0 1.0 1.1 1.1 1.2	4.6×7.1 4.8×7.4 5.3×8.5 6.2×10.1 6.7×11.1 6.7×11.1 8.5×12.5 7.5×12.5 9.5×16.2 4.6×9.6 4.8×10.1 5.3×11.7 6.2×14.0 7.0×15.8 7.0×15.8 7.8×18.2 7.8×18.2 9.5×23.0	0.012 0.011 0.011 0.010 0.0085 0.008 0.0070 0.0065 0.0065 0.012 0.011 0.011 0.010 0.0085 0.008 0.0070 0.0065 0.0065

Note: 1.Insulator:PVC/C type PVC mixture is adopted as insulating material
2.Sheath:PVC/ST4 model PVC mixture should be adopted as the inner sheath.
3.The overall dimension should be within the limitation stipulation of the table.

FAQ

Q1. What kind of products can your company supply?
A: We specialize in supplying network cable, coaxial cable,power cable ,control cable , telephone cable, speaker cable and ect.

Q2. What's your MOQ?
A: The MOQ of long meter cable is 50 km, or we can negociate.

Q3. What's your delivery time?
A: Our delivery time is about 15-20 days after comfriming the deposite, it is based on the quantity of the order.

Q4. What are your payment terms?
A: Normally, we accept T/T in advance, as for other payment term, we can negociate with you.

Q5. What's your trade term ?
A: We can accept FOB, CIF, EXW term.

Q6. What's your conventional packing ?
A: 100m/plastic or wooden drum, 305m/wooden drum or color box. However, we can produce according your demand.

Q7. Can your factory customize cables based on clients' samples or data sheet ?
A: Yes, we can.

Q8. Can you offer me a free sample?
A: Yes,we do,that is a start of business-i think. And you will only pay the cost of delivery,
which we will return it to you when you put the order.

We are specialized in manufacturing of cables for more than 20 years. Can product Building cable, Electrical equipment cable, Automobile cable, Control cable, Coaxial cable, Network communication cable, Audio cable, Monitor cable and the like. We also offer OEM and ODM services.

Located in Huzhou, Zhejiang Province, where is between Shanghai and Hangzhou, we enjoy convenient transportation, thus we can ship goods in Shanghai Port as well as Ningbo Port. Our factory totally covers an area of 3, 000 square meters. High skilled staffs and technical engineers have been dedicated to cable techniques since our company was founded.

At the present, most of our customers are domestic trading companies, and 90% products are exported to all over the word via them; Meanwhile we are developing oversea market by ourselves.

We are keen on building long-term solid relationship with all serious buyers, with sincerity, we welcome you to China to visit our factory and office.
