| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Output: |
3 Channels |
| Supply Voltage: |
5V, 12V, 24V |
| Connectiing Mode: |
Common Anode |
| Output Current: |
<4 a |
| Output Power: |
60W, 144W, 288W |
| Certificate: |
CE&RoHS |
| Warranty: |
2 Years |
| Signal Transmission: |
RF Remote Control |
| Application: |
LED Lighting |
Product Description
4-key wireless Touch RGB LED controller
Remote controller, RGB controller, lighting controller, lights controller, Wireless Led Controller, touch led controller, rf controller
1. Touch RGB RF controller
2. RGB wireless controller for RGB products
3. CE&RoHS approved
4.2years warranty
Main feature
1. Touch-button, ultrathin, light quality, protable.
2. Touch-key count up to 64, up to 64 kinds of mode function, small volume, more key funcation.
3. Easy to use, have color pulley touch screen, all sorts of design and color mode at a glance, can a single point also can continuous touch to realize color mode select, users can speedily choose the needed color, and the static and dynamic mode can change freely.
4. Auto dormancy function, the remote control is without buttons state more than 20 seconds, remote will automatic enter the standby state, realize save electricity, extending battery life.
Technical Parameters
Controller
1. Working temperature: -20-60 degrees
2. Supply voltage: DC5V, 12V, 18V, 24V optional(specify the required voltage on order form)
3. Output: 3 channels
4. Connection mode: Common anode
5. External dimension: L89*W70*H28mm
6. Packing size: L145*W95*H50mm
7. Net weight: 130g
8. Gross weight: 165g
9. Static power consumption: <1W
10. Output current: ≤ 4A (each channel)
11. Output power: 5V: <60W, 12V: <144W, 24V: <288W
Touch remote
1. Working temperature: -20-60 degrees
2. Power supply mode: 28*8mm battery
3. Supply voltage: 12V
4. Static power consumption: 0.036mW
5. Standby current: 3uA
6. Work current: 300uA
7. Emission current: 12mA
8. Remote distance: 30m
9. Standby time: 6 months
|
Mode number |
Function |
Remark |
Mode number |
Function |
Remark |
|
1 |
Static yellow |
Brightness is adjustable, Speed is unadjustable |
11 |
Static blue-green |
Brightness is adjustable, Speed is unadjustable |
|
2 |
Static orange |
12 |
Static light green |
|
3 |
Static red |
13 |
Static green |
|
4 |
Static deep red |
14 |
Static yellow green |
|
5 |
Static pink |
15 |
Static light yellow |
|
6 |
Static purple |
16 |
Three color jumpy changing |
Speed is adjustable, brightness is unadjustable |
|
7 |
Static bluish violet |
17 |
Three color gradual changing |
|
8 |
Static blue |
18 |
Seven color jumpy changing |
|
9 |
Static powder blue |
19 |
Seven color gradual changing |
|
10 |
Static azure |
|
|
