Rg316 Coaxial Cable Wire with N Connector Jumpers Assembly
| Price: |
US $ 0.5-1.5/Meter |
| Min Order: |
100/Meter |
| Pay Type: |
L/C,T/T,D/P |
RG316 Coaxial Cable Wire with N connector Jumpers Assembly
Company profile
Shanghai Xiaowei Equipment Co., Ltd. located Shanghai, China which is branch for overseas market of Jiangsu Huacan Telecommunication Co., Ltd. We are specialist supplier of telecommunication equipment and the total solution for your project.
Jiangsu Huacan Telecommunicaton Co. Ltd is a Private Science and Technology Enterprises and National Hi-tech Enterprise which mainly deals with developing, producing and selling wireless base station antenna and antenna accessories. Founded in 2007, the company has an area of 160 thousand square meters, and more than 2000 staffs.Our company has four production bases: feeder accessories and telecommunication cables; basestation antennas and passive components; coaxial connectors and arrestors; cable assembly and indoor Distributed Antenna.
We are the supplier of civil system intergrators, such as Huawei, ZTE, because of the capacity of wireless communication accessories, and a higher products share. Thanks to high quality and thoughtful after-sales service, many system operators (China Mobile, China Unicom and China Telecom etc.) choose our products for their network.
Our companypassed the certification of ISO9001, ISO14001 and the occupational health system certification. As a member of China Communications Standards Association and with more than 140 patents of all kinds, we often participate in making draft and formulating mobile communication products industry standard.
RG-316 Cable Assembly
Applicable for connecting feeder cables with 8TS equipment and antenna, unnecessary of additional waterproof measures, such as waterproof gel or tape, meets waterproof standard IP68.
Standard lengths: 0.5m, 1m, 1.5m, 2m, 3m, customer special requiremnts on jumper length could be satisfied.
Characteristics & Applications
| Electrical Spec. |
| Vswr | ≤ 1.25 (DC-3GHz) |
| Dielectric withstanding vlotage | ≥1500V |
| Dielectric resistance | ≥1000MΩ(500V DC) |
| Insert loss | It depends on leghth of cable |
| Operating temperature | - 40oC ~ + 85oC |
| Storage temperature | - 70oC ~ + 85oC |
| Weatherproofing standard | IP68 |
| Cable length | Customized |
| Jacket | Heat shrink tubing |
| Connector applicable | N/SMA Type |
| Structure and performance parameters |
| RG316 Cable | RF Connector |
| Material | Inner conductor | Copper clad aluminum wire 7x0.17 (Φ0.51mm) | Inner conductor | Brass, tin phosphorus bronze, tinnedt, hickness≥3μm
Orichalum plating, hickness ≥0.2μm |
| Dielectri material | Physical foam polyethylene(Φ1.25mm) | Dielectri material | PTFE |
| Outer conductor | Copper wire net (Φ2.44mm) | Outer conductor | Brass, tri-alloy plated, thinkness≥2μm |
| Jacket | FPE( Φ2.9mm) | Nut | Brass, ni plated, thickness ≥3μm |
| | | Sealing ring | Silicone rubber |
| Electrical and Mechanical Spec. | Characteristic impedance | 50Ω | Characteristic impedance | 50Ω |
| Vswr | ≤ 1.15(DC-3GHz) | Vswr | ≤ 1.15(DC-3GHz) |
| Standard capacity | 78.4 pF/m | Frenquency | DC-3GHz |
| Velocity | 85% | Dielectric withstanding voltage | ≥1500V |
| Attenuation | ≥90dB | Contact resistance | Inner conducter ≤ 5.0mΩ
Outer conducter≤ 2.5mΩ |
| | | Dielectric resistance | ≥2500MΩ, 500V DC |
| | | Durability | ≥500 |
Detailed Images
Packing & Delivery Packing by Reels
The wood or plywood reels will be used, when the length of cable is more than 300m.
Packing by Paper Boxes
The paper boxes will be used, when the length of cable isn't more than 300m.
For more information, please feel free to contact us!!
| Prod Model: |
RG316 |
| Color: |
Black |
| Inner Conductor: |
CCA |
| Cable Weight: |
0.2kg/M |
| Outer Conductor: |
Copper |
| Connector Applicable: |
N/SMA Type |
| Application: |
RF Cable |
| Conductor Material: |
Copper |
| Cover Material: |
PE |
| Type: |
Cat 1 |
| Certification: |
VDE |
| Model: |
Rg316 |
| Brand: |
OEM |
Shanghai Xiaowei Equipment Co., Ltd (Xiaowei) was established in 2011, Shanghai, which is a company covering cable and accessories manufacturing, engineering service and trading. The main product is coaxial/feeder cable, feeder claim, feeder tools, all kind of the male, female, DIN, connectors, feeder connectors, feeder grouding kit/bar, low loss jumper cable, indoor optic jumper cable and outdoor fiber cable, splitter and coupler, antenna, GPS antenna and all the accessories in the telecom field.
Xiaowei has long cooperation with the Chinese main telecom operators such as China Mobile, China Unicom, China Telecom. And the electric power operator such as National Electric network company, Southern Electric power company. Xiaowei provides total solution for telecommunication, power grid, railway, engineering, green energy, automobile industries, etc.
Xiaowei particularly focused on the QS and creating value for its clients and stakeholders, continuously invest in R&D, marketing & service networks, meeting and exceeding the precise needs of our customers national wide. With the develop of the business, we extend the service to the international trading.
