Sc/APC 3.0mm Fiber Optic Connector

Name: Sc/APC 3.0mm Fiber Optic Connector
Brand: all-electronics-online.com
SKU: 836326145
Availability: InStock
Rating: 5 (42 reviews)

Price:	US $ 0.15/Piece
Min Order:	1000/Piece
Pay Type:	T/T

Contact Supplier

Showroom Product Company Profile

We are professional manufacturer of all kinds of fiber optic connectors in SC, FC, LC, ST, E2000, DIN, D4, MU, MPO , MTP, SMA and etc.

1. Features:

--Good durability

--Good temperature performance

--Easy installation

--Competitive price

2. Applications:

--Fiber Optic Telecommunications

--FTTH (Fiber To The Home)

--CATV & CCTV

--Data Processing Networks

--Telecom Equipment

--Local Area Networks

3. Technical specification:

Insertion loss	SM	≤0.20 dB
Insertion loss	MM	≤0.25dB
Return loss	PC	≥50 dB
	UPC	≥55 dB
	APC	≥65dB
Durability	<0.20 dB typical change, 1000 mating
Ferrule hole sizes	SM: 125.0+1/-0um	concentricity:≤1.0um
	125.5+1/-0um	≤1.0um
	126.0+1/-0um	≤1.0um
	MM:125 um	concentricity:1≤3 um
	127 um	≤3 um
	128 um	≤3 um
Operating temperature	-40~85

For more pictures and more products information, if you want can inquiry directly , thanks

Transmission Medium:	Single-Mode
Structure:	LC
Number Of Cores:	Multi-Core
Ferrule Endface:	PC(',UPC)
Connector Type:	LC
Brand:	Fibercome

Ningbo FiberCome Communication Technology Co., Ltd founded based on three factories( SZ Electronics, ST Network, CG Tel) in the year 2017.

Our business activities begin since year 2007 from smaller factoires, after over 10 years development, we formed a completed fiber optic serial products.

SZ electronics: Mainly produce plastic injection products, we have 12 PCS injection machine, 4 PCS imported machine especially for SMC cabinet producing.

Mainly products are: Fiber box, FTTH box, fiber splice closure, outdoor SMC fiber cabinet with some plastic fiber accessoires.

ST network: Mainly focus on network communication products as: Cat 5, 6, 7 cables and patchcord, patch panel, cable management, network tools, Krone module related

CG tel: Mainly produce metal cabinet and box as - network cabinet, server cabinet, Rack ODF, wall ODF, fiber patch panel related.

And in the year 2018 we enlarge our fiber cable assemble workshop to 40 persons with bigger producing volum

With our professional design and development department, and our workers hard work, we will serve our customers already good quality products to realize mutual benefits. We sincerely hope to do business with any real customers.
