| Prod Model: |
SC |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Color: |
Green |
| Cores: |
Simplex Duplex |
| Fiber Mode: |
Single Mode or Multi-Mode |
| Body Material: |
Plastic or Metal |
| Sleeve Material: |
Ceramic |
| Structure: |
SC |
| Transmission Medium: |
Sm, mm |
| Number Of Cores: |
Simplex Duplex |
| Connector Type: |
Sc |
| Brand: |
ODM |
Product Description
With 15 years history, KOC is a well-established brand popularly accepted in the world-wide market, especially in European and American countries. We are a professional manufacturer of most passive parts such as patch-cord, connector, adapter, attenuator,splitter, WDM serious. For more detail, please check on our website www.koc.com.cn.
In case of need, please do not hesitate in contacting us.
APPLICATIONS
CATV
Metro
Telecommunication networks
Local Area Networks (LANs)
Test equipment
Data processing networks
FEATURES
Low insertion loss
Good exchangeability and durability
High temperature stability
All parts compliant with ROHS
polytypic
APPLICATIONS
Active device termination
Test equipment
Passive optical fiber network
Data processing network
Telecommunication network
CATV, LAN, WAN
SPECIFICATIONS (Hybrid type adapter)
ITEM | PARAMETER |
| Applicative adapter type | SC,LC,FC,ST,MU,D4,DIN |
| Fiber mode | Single mode | Multi-mode |
| Adapter color | Blue, green, metal | Beige, metal |
| Test wavelength | 1310nm, 1550nm | 850nm, 1300nm |
| Insertion Loss | typical≤0.15dB,Max≤0.20dB | typical≤0.15dB,Max≤0.20dB |
| Repeatability | ≤0.10dB |
| Interchangeability | ≤0.20dB |
| Durability | ≤0.20dB Max change,1000 mating |
| Channels | Simplex,Duplex,4channels |
| Body material | Plastic or metal |
| Sleeve material | Ceramic(ZrO2) or Customized |
| Operating Temperature | -20ºC to +70ºC |
| Storage Temperature | -40ºC to +85ºC |
