Prod Model: |
12V36AH-MF |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
New JIS: |
55D23r |
Voltage: |
12V |
R.C.: |
100min. |
CCA.: |
420A |
Terminal Lay-out: |
a -1 |
Plate: |
11 |
Brand: |
Ruiyu or OEM Service |
Weight: |
13.8kg |
Warranty: |
One Year |
MOQ: |
150 |
Type: |
Lead-Acid Batteries |
Rechargeable: |
Chargeable |
Discharge Rate: |
Low Discharge Rate |
Shape: |
Square Battery |
Nominal Voltage: |
12V |
Usage: |
Boat |
Product Description
Tech Specification:
1. Capacity.: 36AH to 220ah
2. Voltage: 12V
3. Applications: Starting battery for cars, buses, trucks and other vehicles
4. Certificate: ISO, CE, IEC60095, SONCAP etc
5. Packaging: Cartons & pallets
6. Delivery: Within 30 days after signing contract and receiving 30% deposit.
7. Deliver from qingdao, China.
8. Free OEM production available (customers provide Brand & Packaging design)
Superior performance 12V car battery:
----Composite Separator
Ultra-fine glass fiber composite separator, with light weight, small resistance, high acidity absorption and strong ion migration ability in the sulfuric acid solution, improves its battery voltage and starting current to the maximum, thus keeping the battery capacity in a good state all long.
---Comparison of Service Life between General Separator and Composite Separator
Ultra-fine glass fiber composite separator, with the fiber diameter of 2-3um, is arranged disorderly in a network structure. The strong adsorption and breakover capabilities of the battery electrolyte can effectively condensate active substances and prevent them from dropping off, thus extending the battery life.
---Battery Life
The adoption of Sb-free Pb-Sn-Ca special alloying technology effectively guarantees the contents of lead dioxide and spongy lead in the positive and negative plates. The battery can be put into use directly after adding liquid, no need to be charged. Its super-charged performance distinguishes the product from others.
---Excellent Performance Chart of Pb-Ca Alloy
The accumulate plate made of high-purity Pb-Ca alloy has extraordinary oxidation and corrosion resistance capabilities. The adverse effect brought about by hydrogen evolution of general Sb alloy plate is avoided; The water loss of the accumulator slowed down, and the cycle index improved.
---Comparison of Self-discharge between General
Accumulator and Pb-Sb-Ca Alloy Accumulator
The Pb-Sb-Ca alloy grid offers more excellent characteristics of oxidation resistance, corrosion resistance and less water loss than the general Sb alloy grid, which can minimize the self-discharge and maintain its good starting performance even after long-term storage.
Voltage: 12 V
Capacity: 32AH to 230AH
Dimensions: 197x130x220 235x130x220 268x173x225 305x173x230 405x173x230
506x181x233 506x217x233 506x260x233 210x175x175/190
238x175x175/190 268x175x175/190 340x175x175/190
Terminal: A/E B
Layout hd: 1 /0
Warranty: 12 months
Moq: 150 pcs/item
MAINTENANCE FREE AUTOMOTIVE BATTERIES-JIS STANDARD. |
New Type |
Old Type |
Voltage |
Capacity |
R.C. |
C.C.A |
Dimensions (mm) |
Layout |
Terminals |
(V) |
C20(Ah) |
(Min) |
(A)-18°C |
L |
W |
TH |
55D20R |
|
12 |
50 |
76 |
350 |
200 |
170 |
220 |
1 |
A |
55D20L |
|
12 |
50 |
76 |
350 |
200 |
170 |
220 |
0 |
A |
48D26R |
N50 |
12 |
50 |
80 |
350 |
260 |
170 |
220 |
1 |
A |
48D26L |
N50L |
12 |
50 |
80 |
350 |
260 |
170 |
220 |
0 |
A |
55D26R |
N50Z |
12 |
60 |
103 |
420 |
260 |
170 |
220 |
1 |
A |
55D26L |
N50ZL |
12 |
60 |
103 |
420 |
260 |
170 |
220 |
0 |
A |
65D26R |
|
12 |
65 |
113 |
430 |
260 |
170 |
220 |
1 |
A |
65D26L |
|
12 |
65 |
113 |
430 |
260 |
170 |
220 |
0 |
A |
75D26R |
NS70 |
12 |
65 |
113 |
430 |
260 |
170 |
220 |
1 |
A |
75D26L |
NS70L |
12 |
65 |
113 |
430 |
260 |
170 |
220 |
0 |
A |
80D26R |
NX110-5 |
12 |
70 |
134 |
560 |
260 |
170 |
220 |
1 |
A |
80D26L |
NX110-5L |
12 |
70 |
134 |
560 |
260 |
170 |
220 |
0 |
A |
55D23R |
|
12 |
60 |
100 |
420 |
230 |
170 |
225 |
1 |
A |
55D23L |
|
12 |
60 |
100 |
420 |
230 |
170 |
225 |
0 |
A |
65D23R |
|
12 |
65 |
112 |
430 |
230 |
170 |
225 |
1 |
A |
65D23L |
|
12 |
65 |
112 |
430 |
230 |
170 |
225 |
0 |
A |
75D23R |
|
12 |
65 |
112 |
450 |
230 |
170 |
225 |
1 |
A |
75D23L |
|
12 |
65 |
112 |
450 |
230 |
170 |
225 |
0 |
A |
65D31R |
N70 |
12 |
70 |
134 |
480 |
310 |
170 |
225 |
1 |
A |
65D31L |
N70L |
12 |
70 |
134 |
480 |
310 |
170 |
225 |
0 |
A |
75D31R |
N70Z |
12 |
75 |
137 |
500 |
310 |
170 |
225 |
1 |
A |
75D31L |
N70ZL |
12 |
75 |
137 |
500 |
310 |
170 |
225 |
0 |
A |
95D31R |
NX120-7 |
12 |
80 |
160 |
620 |
310 |
170 |
225 |
1 |
A |
95D31L |
NX120-7L |
12 |
80 |
160 |
620 |
310 |
170 |
225 |
0 |
A |
Shandong Ruiyu Accumulator Co., Ltd. Was established in 1980, it is the top 10 Automotive Start Battery manufacturers in China, Also the drafter of Chinese national battery industry standard: "GB" standard.
Our company own the modern battery production system include lead company, injection company, plate company, assembly company and own the professional lab, test and inspection equipment.
We have the professional and experienced QC group, R&D team, they are our core-competitiveness, The company has obtained many certificates such as ISO19001, ISO14001, ISO18000, ISO/TS 16949, OHSAS18001, CQC, IEC60095-1, CE, SONCAP, and SASO. And we also have obtained 37 patents on battery and battery technology.
Our Products are in great demand in domestic market also has been shipped to many countries of Asia, Europe, North America, Oceania, South America and Africa. And enjoy good reputation of batterie's quality and the performance.
