Single Core XLPE Insualted Copper Wire Armour 11kv Aluminum Power Cable
| Price: |
US $ 10-11/Meter |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
500/Meter |
| Pay Type: |
L/C,T/T,D/P,Western Union |
single core xlpe insualted copper wire armour 11KV aluminum power cableConductor shape: Compression CircularStandard: IEC 60502-1997 Or equivalent DIN, BS, AS/NZS, JIS, ASTM, IS, etc.Package: Steel or wooden DrumAdditional Options: Halogen free, flame retardant, Low smoke, Anti-termite. Technical details: Conductor: Conductor cross section of 800mm2 or below is stranded through compacting round core, with better roundness and higher compacting coefficient. Conductor cross section more than 800mm2 is made by segment of Milliken method to minimize skin connecting and alternating current impedance and increase power transmission capacity of cable. Insulation: XLPE. Product line: CCV Metallic screen/sheath: Copper wire, copper tape or copper wire+tape Armor: Steel tape Outer sheath: PVC, MDPE, HDPE, LDPE Characteristic of use: 1. Allowable max. long-time operation temperature of cable conductor: 90°C2. Allowable Max. short circuit temperature of cable conductor (max. sustaining period not exceeding 5s): 250 °C 3. Allowable Min. bending radius when laying cable, generally 20 times of the cable diameter
| Prod Model: |
YJLV32 YJV32 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Rated Voltage: |
11kv |
| Cross Section: |
25mm2-630mm2 |
| Cores: |
Single or Three |
| Certificate: |
UL.CE.ISO |
| Armour: |
Steel Wire /Aluminum Wire/Copper Wire |
| Conductor: |
Alulminum or Copper |
| Type: |
Insulated |
| Conductor Type: |
Stranded |
| Application: |
Underground |
| Conductor Material: |
Copper |
| Insulation Material: |
XLPE |
| Certification: |
CCC |
| Brand: |
Ren Da |
Established in 1993, Hebei Huatong Wires and Cables Group Co., Ltd covers an area more than 220, 000 square meters, owning more than 420 sets manufacturing equipment and more than 250 sets of testing equipment or apparatus. Our annual production capacity is 3 billion Chinese Yuan. Now there are more than 800 employers in our company, among which more than 150 are technicians. With the continuous efforts from all the employers, Hebei Huatong Wires and Cables Group Co., Ltd has realized great development to become a modern enterprise and one of the comprehensive, large-scale enterprises in domestic wire and cable industry. Our products are widely used in the field of electric power, coal, metallurgy, petrochemical industry, railway, national defense, construction, aviation and other national key projects. We are JV with Furukawa(Japanese company) for rubber serial cable (minding cables, welding cables. Submersible oil pump cables, . )and also JV with Riken(Japanese company) for elevator cables. Our products have extensive influence and good reputation in both domestic and worldwide market, such as the United States, Holland, Italy, Russia, Britain, Australia, New Zealand, Ethiopia, Ghana, Algeria, South Africa, Congo, Middle East and Southeast Asia countries and so on.
Products: Power Cable, Rubber Cable, UL standard building wire cable
Certificates:
Certificate of UL. CE, KEMA, TUV, Bureau Veritas, Lloyd, IEC, GL, SA, NK, KR and "National Industrial Production License", "Certificate of Recommended Enterprises and Products for National Grid", "Adopting International Standard Certificate", and "High-Tech Enterprise Certificate", "Certificate of High Quality Products", "Certificate of Scientific and Technological Achievements", "Qualified Supplier Certificate", "China Classification Society Certificate of Works Approval", "Det Norske Veritas Type Approval Certificate", "Railway Product Certificate", "Safety Certificate of Approval for Mining Products", "National Mandatory Product Certification", "Certificate for China Compulsary Products Certification" and "Practical New-Type Patent Certificate"
