Sjw-Wb-80kVA Industrial Micro-Chip (CPU) , Non-Contact (contactless) Compensation Voltage Regulator/Stabilizer

Name: Sjw-Wb-80kVA Industrial Micro-Chip (CPU) , Non-Contact (contactless) Compensation Voltage Regulator/Stabilizer
Brand: all-electronics-online.com
SKU: 750310435
Availability: InStock
Rating: 5 (53 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	5/Piece
Pay Type:	L/C,T/T,Paypal,Money Gram,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	SJW-WB-80KVA
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Current Type:	AC
Phase:	Three Phase
Application Range:	Used in Region Where The Net Voltage Is Flucuating
Brand:	Conpo
Usage:	Three-Phase, Four-Wire System
Frequency:	50Hz/60Hz

Product Description

1.Summary:
SJW-WB serial Industrial Micro-chip(CPU), Non-contact(contactless) Compensated Voltage Stabilizer which is a new generation quick stabilizing voltage equipment developed by our company through many years hard work. It adopts the newest high speed operating chip control technology, fastest AC sampling technology, efficient calibrate technology, current vanish switch and fast compensate voltage stabilizing technology. They control several available silicon slices by special sequence to control the voltage connections, then to change the main voltage and voltage polar. It composes of insulation transformer, SCR mode, CPU control core, fast voltage stabilizing technology and security equipments, and accomplishes non-contact control, safe, high efficient and energy conservation. It is the perfect match of voltage translator and SCR on/off switch.

2. Application:
This serial product is widely used in Industry, Traffic, Post, Defense, Rail Ways, Science Lab, Large Electronic Machine, Metal Processing Equipments, Production Line, Elevator, Medical Equipments, Air Conditioner, Broadcast Television, Home Use Electronic, Building Lighting Equipment and other Equipments which need stable voltage, and are highly suitable to the equipments which needs high reliable and high stable power supply, or equipments in high amplitude of fluctuation voltage net.

3. Features:
1). CPU intelligent SCR control, digital circuits, stable and reliable.
2). Large-screen LCD, user-friendly man-machine interface.
3).Three phases regulation, no contact, no abrasion, no spark and maintenance free.
4). Regulator speed to 0.03S can be accessed by all types of generators.
5). Efficiency is more than 98%, and power consumption less than 1%, save electricity to save money.
6). Anti-interference, cleaning ability, so that the output power completely pure.
7). With overload, short load, short circuit, lack of phases, and automatically bypass protection function
Note: Particularly suitable for high reliability, high stability power electrical equipment, and grid fluctuations, the voltage instantaneous mutation harsh electrical environment!

4.Specifications:

SJW-WB Industrial Micro-chip(CPU), Non-contact(contactless)Compensated AC Voltage Stabilizer(Intelligent SCR controlled system)
Input voltage	380V+/-20% (like +/-15%, 30%, 40% etc. large range can be customized, when ordering, please specify it!)
Input frequency	50Hz/60Hz
Output voltage	380VAC
Output voltage accuracy	+/-1~5% adjustable
Filter distortion	No additional waveform distortion(static state)
Power factor	0.8
Response time	≤0.03s
Anti-interference	Arrester, EMI filter, LC filter(Optional, please specify it when ordering)
Over or under voltage protection	Output phase voltage over 10%, cut-off input or transfer to bypass phase incessantly
Overload protection	Electronic detection, cut off input in three minutes
Bypass protection	Automatically transfer to bypass in case of failure
Phase lack protection	Cut-off automatically
Overload ability	5times rated current 1second
LCD display	Voltage, current and abnormal etc.
Alarm	LCD display and alarm
Ambient temperature	0~45ºC
Altitude	<4000M
Communication interface	Machine configuration RS-232 interface(Optional, please specify it when ordering)
Noise	≤45dB(1m distance)
Cooling system	Cooling fan
*Customize option for specification and availability, please contact CONPO!*

4. Packing Details:

Model	Main. Specifications	Qty. per pkg	Package size	Remarks
SJW-WB-20KVA	3Phase, Vi: 380V+/-20%, Vo: 380V+/-2.5%, Micro-chip & Non-contact AVR, LCD display	1pc	420820840mm	Custom-made specifications are acceptable
SJW-WB-30KVA	3Phase, Vi: 380V+/-20%, Vo: 380V+/-2.5%, Micro-chip & Non-contact AVR, LCD display	1pc	420820840mm	Custom-made specifications are acceptable
SJW-WB-40KVA	3Phase, Vi: 380V+/-20%, Vo: 380V+/-2.5%, Micro-chip & Non-contact AVR, LCD display	1pc	420820840mm	Custom-made specifications are acceptable
SJW-WB-50KVA	3Phase, Vi: 380V+/-20%, Vo: 380V+/-2.5%, Micro-chip & Non-contact AVR, LCD display	1pc	420820840mm	Custom-made specifications are acceptable
SJW-WB-60KVA	3Phase, Vi: 380V+/-20%, Vo: 380V+/-2.5%, Micro-chip & Non-contact AVR, LCD display	1pc	420820840mm	Custom-made specifications are acceptable
SJW-WB-80KVA	3Phase, Vi: 380V+/-20%, Vo: 380V+/-2.5%, Micro-chip & Non-contact AVR, LCD display	1pc	4708301220mm	Custom-made specifications are acceptable
SJW-WB-100KVA	3Phase, Vi: 380V+/-20%, Vo: 380V+/-2.5%, Micro-chip & Non-contact AVR, LCD display	1pc	4708301220mm	Custom-made specifications are acceptable
SJW-WB-120KVA	3Phase, Vi: 380V+/-20%, Vo: 380V+/-2.5%, Micro-chip & Non-contact AVR, LCD display	1pc	5609001340mm	Custom-made specifications are acceptable
SJW-WB-150KVA	3Phase, Vi: 380V+/-20%, Vo: 380V+/-2.5%, Micro-chip & Non-contact AVR, LCD display	1pc	5609001340mm	Custom-made specifications are acceptable
SJW-WB-180KVA	3Phase, Vi: 380V+/-20%, Vo: 380V+/-2.5%, Micro-chip & Non-contact AVR, LCD display	1pc	5609001340mm	Custom-made specifications are acceptable
SJW-WB-200KVA	3Phase, Vi: 380V+/-20%, Vo: 380V+/-2.5%, Micro-chip & Non-contact AVR, LCD display	1pc	5609001340mm	Custom-made specifications are acceptable
SJW-WB-250KVA	3Phase, Vi: 380V+/-20%, Vo: 380V+/-2.5%, Micro-chip & Non-contact AVR, LCD display	1pc	12408401700mm	Custom-made specifications are acceptable
SJW-WB-300KVA	3Phase, Vi: 380V+/-20%, Vo: 380V+/-2.5%, Micro-chip & Non-contact AVR, LCD display	1pc	12408401700mm	Custom-made specifications are acceptable
SJW-WB-400KVA	3Phase, Vi: 380V+/-20%, Vo: 380V+/-2.5%, Micro-chip & Non-contact AVR, LCD display	1pc	12408401700mm	Custom-made specifications are acceptable
SJW-WB-500KVA	3Phase, Vi: 380V+/-20%, Vo: 380V+/-2.5%, Micro-chip & Non-contact AVR, LCD display	1pc	12408401700mm	Custom-made specifications are acceptable
SJW-WB-600KVA	3Phase, Vi: 380V+/-20%, Vo: 380V+/-2.5%, Micro-chip & Non-contact AVR, LCD display	1pc	12408401700mm	Custom-made specifications are acceptable
SJW-WB-800KVA	3Phase, Vi: 380V+/-20%, Vo: 380V+/-2.5%, Micro-chip & Non-contact AVR, LCD display	1pc	15408402040mm	Custom-made specifications are acceptable
SJW-WB-1000KVA	3Phase, Vi: 380V+/-20%, Vo: 380V+/-2.5%, Micro-chip & Non-contact AVR, LCD display	1pc	15408402040mm	Custom-made specifications are acceptable
SJW-WB-1200KVA	3Phase, Vi: 380V+/-20%, Vo: 380V+/-2.5%, Micro-chip & Non-contact AVR, LCD display	1pc	15408402040mm	Custom-made specifications are acceptable
SJW-WB-1600KVA	3Phase, Vi: 380V+/-20%, Vo: 380V+/-2.5%, Micro-chip & Non-contact AVR, LCD display	1pc	15408402040mm	Custom-made specifications are acceptable
SJW-WB-2000KVA	3Phase, Vi: 380V+/-20%, Vo: 380V+/-2.5%, Micro-chip & Non-contact AVR, LCD display	1pc	224012402040mm	Custom-made specifications are acceptable
SJW-WB-2500KVA	3Phase, Vi: 380V+/-20%, Vo: 380V+/-2.5%, Micro-chip & Non-contact AVR, LCD display	1pc	224012402040mm	Custom-made specifications are acceptable
SJW-WB-3000KVA	3Phase, Vi: 380V+/-20%, Vo: 380V+/-2.5%, Micro-chip & Non-contact AVR, LCD display	1pc	224012402040mm	Custom-made specifications are acceptable

CONPO Power Tech. Co., Ltd specializes in producing Power Source as a member of China Power Supply Society. Since being founded, we has been insisting on the theoretic guideline of "Science & Technology is the first productive force" and holding up brand strategy as the guide, relying on forward understanding about power supply technology, perfect craft and unwearied pursuing to quality, we can show top quality power supply products, and set up fine image in Chinese market and abroad market.

CONPO has the modern workshops and advanced production devices, besides we always introduce technology positively, reform craft continuously, devote to researching and developing Voltage Stabilizer/Voltage Regulator, Uninterruptible Power Supply(UPS), Power Inverter, Solar Panel, Solar Controller, Solar Inverter and Solar Generator, Switching-mode Power Supply(SMPS), Transformer, Frequency Inverter etc. Power and Solar products. In addition, we try to find excellent administrators and technical talents, through years on working hard, we has been improved on the aspect of quality, power supply varieties, producing scale, management mode, so products manufactured by us have reached advanced technical level, they are not only popular with a great of customers in China, but also in foreign countries.

CONPO Products have been approved by Quality Supervision & Inspection(QSI), Insured by PICC, and also have CE, RoHS, UL, CCC certificates. We insist on the policy of developing by quality on the time, and also have passed ISO9001: 2000 Quality Management System Certificate. Relying on rich economic strength, fine production engineering, innovating management mode, we can dare to meet kinds of challenges from China entering WTO that is helpful for establishing reinforced foundation of international business.

We are keeping our business principle for " Approaching the first-class management, Producing the first-class products, Providing the first-class service". All CONPO staffs are working hard and constantly innovate. Honest CONPO are welcome to all users to fighting a better tomorrow hand in hand.
