SMT Work Custom PCBA Assembly

Name: SMT Work Custom PCBA Assembly
Brand: all-electronics-online.com
SKU: 676869772
Availability: InStock
Rating: 4.9 (21 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB
Min Order:	1000/Piece
Pay Type:	T/T,Western Union,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	BP013
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Metal Coating:	Copper
Mode Of Production:	SMT
Layers:	Double-Layer
Base Material:	FR-4
Certification:	ISO
Customized:	Customized
Condition:	New

Product Description

What products and services we offer:

Excepting OEM PCB, i.e. Telecommunication, PC Add-On Card, IT Application, Network Device, Multi Layers FR-4 product, we have some outstanding products as follows:

1. Carbon Built on PCB:Apply for Thick Film Technology to make the PCB with buried resistors or touch pad function.
2. Thin PCB:Less than 16 mil thickness in 4 or 6 layers FR-4 production is another challenge for our production capability.
3. CSP // BGA PCB:Those kinds of PCB are increasing and we expect the quantity will be over 10% of our production in coming years.
4. Special Service: In addition to devote in normal PCB process, our engineering team also provide design support as requested by clients

Brain Power's Strength:

Excellent quality stability.
Excellent process and handling control. (Thus impedance yield can achieve to 98% !)
High customer satisfaction.
Thin Board Production with 2 mils core.
Different Impedance technique leader in the RAM module market.
Tight board thickness tolerance(+/- 3 mils) control.

Year Item	2015	2016E
Year Item	2015	Mass Production	Sample
Max. Multilay ers	20	20	24
Board Thickness Tolerance (mil/mm)	50±3mil / (±0.076mm); 14±2mil / (±0.05mm);	50±3mil / (±0.076mm); 14±2mil / (±0.05mm);
Min. hole size (mil)	Mechanical 6mil (0.15 mm), Laser 4mil (0.10 mm)	Mechanical 6mil (0.15 mm), Laser 4mil (0.10 mm)	Mechanical 6mil (0.15 mm), Laser 3.5mil (0.089 mm)
Finished Aspect ratio	12:1.	12:1.	16:1.
Min. line Width/Space (mil)	2.0/2.0mil; (0.050/0.050 mm)	2.0/2.0mil; (0.050/0.050 mm)	1.6/1.6mil;(0.040/0.040mm)
Impedance (ohm)	+/-10%	+/-10%	+/-7%
Dif f erential Impedance (ohm)	+/-10%	+/-10%	+/-7%
Gold Finger thickness(u"/um)	80u" (2um)	80u" (2um)	80u" (2um)
Router tolerance	±3.0mil (0.076mm)	±3.0mil (0.076mm)	±2.0mil (0.051mm)
Surf ace treatment	ENIG,H/G plating,OSP,Immersion sliver		ENIG,H/G plating,OSP,Immersion sliv er,Immersion Tin,ENEPIG
Application / Lamination
Standard and extended	FR4(TG140-180°),ANTI-CAF,Halogen Free, Low z-axis expansion(Lead Free)
Special perf ormance	High TG(BT)		High TG(BT),Low loss,FPCB material
High f requency	PTFE,Ceramic

Before quote, please offer:

Gerber file
Base material: FR4/ AL/ FPC/ CEM-1/ CEM-3/ 94v0/ Rogers
Board thickness
Surface treatment
Copper thickness
Color of solder mask and silkscreen

Shenzhen Tengyuxin Technology Co., Ltd is a professional PCB & PCBA manufacturer which specialized in manufacturing SS, DS, HDI and multilayer PCB. Our modern factory is located in Qingyuan Guangdong which has more than 3000 staffs and 101, 000 square meters workshop. We can provide all-in -one service ( R&D, manufacturing and sales) for you
