SSR-400A Mager Solid State Relay

Name: SSR-400A Mager Solid State Relay
Brand: all-electronics-online.com
SKU: 684107552
Availability: InStock
Rating: 4.3 (81 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	10/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Product Details:
Model No: SSR-400A
1) Small volume and dimensions
2) Universal fit
3) Safety EGIS cover
4) Zero current turn-off
5) Input loop and output loop light isolated
6) LED indicator (function and alarm)

Specifications

Solid State Relay
Specifications
Input		3-32 VDC (fixed current ) 13mA 12V
Output		24-380VAC/90-480VA (10-75AMP)
Control Type		Zero Cross Trigger
Response time		ON<20ms/OFF<40ms
Voltage Withstand		Over 2.5Kvac/1MIN
Insulating strength		Over 50m/500VDC
Dimension		62.544.823.2mm
High strength ABS engineering plastics, gray case with LED indicator
Basic type	SSR-10DA	SSR-25DA	SSR-40DA	SSR-50DA	SSR-60DA	SSR-75DA
Hight voltage type		SSR-25DA-H	SSR-40DA-H	SSR-50DA-H	SSR-60DA-H	SSR-75DA-H

Input		Trimmer / 250K to 110V
Output		24-380VAC (10-40AMP)
Control Type		Phase control
Voltage Withstand		Over 2.5 Kvac/1MIN
Insulating strength		Over 50m/500VDC
Dimension		62.544.823.2mm
High strength ABS engineering plastics,gray case with LED indicator
Basic type	SSR-10VA		SSR-25VA		SSR-40VA
High voltage type

Input		80-250VAC
Output		24-380VAC/90-480VAC(10-75AMP)
Control Type		Zero Cross Trigger
Response time		ON<20ms/OFF<40ms
Voltage Withstand		Over 2.5 vac/1 MIN
Insulating strength		Over 50m/500VDC
Dimension		62.5X44.8X23.2mm
High strength ABS engineering plastics, gray case with LED indicator
Basic type	SSR-1 0AA	SSR-25AA		SSR-40AA		SSR-75AA
Hight voltage type		SSR-25AA-H		SSR-40AA-H		SSR-75AA-H

Input		3~32VDC 12mA@12V
Output		5~60VDC/5~200VDC(5~80AMP)
Insulating strength		Isolated by photocouple
Voltage withstand		ON 10ms/OFF 20ms
Control type		Over 2.5Kvac/1MIN
Response time		Over 50m/500VDC
Dimension		62.5X44.8X23.2mm
High strength ABS engineering plastics, gray case with LED indicator
Basic type	SSR-05DD	SSR-10DD	SSR-25DD	SSR-50DD	SSR-80DD
High voltage type		SSR-10DD-H	SSR-25DD-H	SSR-50DD-H	SSR-80DD-H

Prod Model:	SSR-400A
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Current:	400A
