Product Description
Application
ELC1-D/W series AC Contactor issuitable for using in the circuits up to the rated voltage 660V AC 50HZ or 60HZ, rated current up to 620A, for making, breaking, frequently starting & controlling the AC motor.Combined with the auxiliary contact block, timer delay & machine interlocking devece etc, it becomes the delay contactor, mechanical inter contactor, star-delta starter. With the thermal relay, it is combined into the electromagnetic starter. The contactor is produced according to IEC/EN60947-4, VDE0660 & BS5452.
| Specification |
Type | 220V
230V
KW | 380V
400V
KW | 660V
690V
KW | 200V
440V
HP | 240V
500V
HP |
460V
HP |
600V
HP |
AC-3
440V |
NO |
NC
|
| ELC1-D0910/W |
2.2 |
4 |
4 |
4 |
5.5 |
5.5 |
- |
9 | 1
_ | -
1 |
| ELC1-D0901/W |
| ELC1-D1210/W |
3 |
5.5 |
5.5 |
5.5 |
7.5 |
7.5 |
- |
12 | 1
- | -
1 |
| ELC1-D1201/W |
| ELC1-D1810/W |
4 |
7.5 |
9 |
9 |
10 |
10 |
- |
18 | 1
- | -
1 |
| ELC1-D1801/W |
| ELC1-D2510/W |
5.5 |
11 |
11 |
11 |
15 |
15 |
- |
25 | 1
- | -
1 |
| ELC1-D2501/W |
| ELC1-D3210/W |
7.5 |
15 |
15 |
15 |
18.5 |
18.5 |
- |
32 | 1
- | -
1 |
| ELC1-D3201/W |
| | | | | | | | | | | |
| Items Model |
D09 |
D12 |
D18 |
D25 |
D32 |
| Rated conventional heating current(A)AC-1 | 20 | 20 | 32 | 40 | 50 |
| Rated insulation voltage(V) | 690 | 690 | 690 | 690 | 690 |
| Electric AC-3 | 1200 | 1200 | 1200 | 1200 | 1200 |
Operating
frequency Life AC-4
(operations/h) |
300 |
300 |
300 |
300 |
300 |
| Mechanical life | 3600 | 3600 | 3600 | 3600 | 3600 |
Electric life AC-3
(X 103 operations) AC-4 | 1000
200 | 1000
200 | 1000
200 | 1000
200 | 1000
200 |
| Mechanical life(X 106 operations) | 10 | 10 | 10 | 10 | 10 |
| Matched fuse type | RT16-20 | RT16-20 | RT16-32 | RT16-40 | RT16-50 |
