Thermocouple for Heating Furnace

Thermocouple for Heating Furnace
Price: Negotiable/Piece
Min Order: 1000/Piece
Pay Type: L/C,T/T,D/P,Western Union,Paypal
Installation Type: Free Standing
Output Signal Type: Potential
Production Process: Welding
Material: Copper

Product Description

Product Description:
1) Thermocouple specified for gas cooker, gas oven, gas heater, gas water heater etc.
2) Applicable gas families: NG/LPG/propane/butane
3) No-load potential: ≥12mv(according to request) (650°C)
4) Inner resistance: 5-50±3mΩ
5) Length: 20-1800mm
Technical parameter:
Heating characteristic≥12mV (within 20s at 650°C)
Cooling characteristic≤1.5mV(within 60s)
Range of length150mm(5.9inch)~ 1800mm(71inch)
Range of resistance(10~50)±3 mΩ
Operating conditions:
Range of ambient temperatures:   0°C ~ 52°C (32°F to 125°F)
Maximum operating temperatures:
Thermocouple Tip:750ºC / 1382°F
Thermocouple Wire:180ºC / 356°F
Cold Junction:150 ºC / 302°F   Injector(Burner):750ºC / 1382°F
ZhuZhou ChenXin Induction Equipment Co., Ltd is engaged in the development and production of high temperature graphitization furnace and we have 9 patent license authorized by Chinese government.

Our management concept is that we continually focus on excellent human resource, directed by the market requirement and win our reputation by advanced technology development.

Our main products are high temperature graphitization furnace, carbonization furnace, melting furnace, sintering furnace, and high-frequency induction heating equipment, industrial control equipment. Moreover, we also engaged in the R&D manufacturing, marketing of related technical service of non-metallic composite materials, C/C composite, technical services of non-metallic composite materials, C/C composite materials. And we also offer our customer with accessories which include graphite, carbon fiber cloth, carbon rope, carbon fiber felt, high-conductivity film. Our products are widely used in a variety of areas for processing and manufacturing industry, such as aerospace, transportation, machinery, metallurgy, military equipment, rail transportation and so on.

Our company has won a good reputation at home and abroad. We have a strong mechanical and electrical design and manufacturing capability. Good economic environment, perfect service facilities to establish an efficient network of product sales and technical service. Our after-sale service was highly praised by our old customers and we will continuously dedicate on this to guarantee our customer with trusted and worry free use of our machine.
