Toroidal high Frequency and high Power Magnetic Ring Inductor (116.8uH 30A)

Name: Toroidal high Frequency and high Power Magnetic Ring Inductor (116.8uH 30A)
Brand: all-electronics-online.com
SKU: 831121335
Availability: InStock
Rating: 4.4 (117 reviews)

Price:	US $ 4.3-5/Piece
Min Order:	100/Piece
Pay Type:	T/T

Contact Supplier

Showroom Product Company Profile

Toroidal hign frequency and hign power Magnetic Ring Inductor (116.8uH 30A)

Use CS508060 magnetic ring (or equivalent magnetic ring)
Size of magnetic core:long51.7*wide30.9*high14.35mm
Line warp: 0.2*100*2
Winding number:40
Current density:3.27
DC resistance:4.91m
Copper loss:3.070W
L@0A:116:8μH 30A
[email protected]:60.89μH (H=98.71Oe)
[email protected]:42.18μH (H=139.60Oe)

Prod Model:	116.8uH 30A
Advange:	ODM/OEM
Certificate:	UL/Rosh/Ce
Type:	Choke Inductor
Structure:	Inductive Choke
Brand:	Sny

Shanghai Shen Yang Electronic Technology Co., Ltd, Professional research and development production of high-end electronic products. The quality is stable and reliable, Advanced technology.

Main industries involved: Energy conservation and environmental protection equipment industry\The power equipment\New energy vehicles\Medical apparatus and instruments\Military products\Electronic appliances industry, etc.

The main products: High-frequency transformer\Inductor\Switching power supply\Sine wave inverter \Intelligent control module\Electronic appliances industry, etc.

Purpose of the enterprise: Take the quality as the fundamental\Occupy the market with advanced technology\In order to create brand credibility.

Enterprise culture: Enterprise is the home of employees\Our people are the root of the enterprise\On the basis of people and management\With the strength of science and technology.

Innovation\Pragmatic\Dare to, Contribution to the society, with all my heart, Profit benefit the people.
