U Shape Mosi2 Heating Element
| Price: |
US $ 20-380/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
6/Piece |
| Pay Type: |
T/T,Western Union |
| Prod Model: |
U shape |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Grade: |
1700c/1800c |
| Dia: |
3/6, 4/9, 6/12, 9/18, 12/24 etc. |
| Structure Material: |
Non-Metallic Material |
| Application: |
Heater |
| Principle: |
Resistance Heating |
Product Description
U shape MoSi2 heating element:
Molybdenum disilicide(MoSi2) heating elements for element temperatures up to 1800C(3270F), Our MoSi2 heating elements are available as straight or bent elements in a wide range of shapes and sizes, All characterized by long life and consistant perfomance.1. Specification:
Type: 1700C/1800C
Dia: 3/6, 4/9, 6/12, 9/18, 12/24 etc.
Type: I, U, W, and U-right angle shapes, etc
And we can produce according to your requests. | 2. Physics Characters: |
| Volume Density | Bending Strength | Vickers Hardness | Porosity | Water absorption | Heating Elongation Rate |
| 5.5g/cm3 | 15-25 kg/cm3 | (HV)570kg/mm2 | 7.40% | 1.20% | 4% |
3. Chemistry Character
MoSi2 heating element is used in the high temperature under oxidizing atmosphere. It will form the SiO2 film which can keep the element from being melted. During the oxidizing process, the SiO2 protecting film is formed again when the element continues to be used. The MoSi2 heating element must not be used in the temperature between 400C and 700C for a long time, otherwise the element will be cremated under the strong oxidizing function in the low temperature.4) The Using Temperature Under the Different Atmospheres
Atmosphere |
The Maximum Using Temperature of Elements |
1700 |
1800 |
No2 ,Co2 ,O2 ,Air |
1700°C |
1800°C |
He ,Ar ,Ne |
1650°C |
1750°C |
So2 |
1600°C |
1700°C |
CO ,H2 |
1500°C |
1600°C |
Wet H2 |
1400°C |
1500°C |
Dry H2 |
1350°C |
1450°C |
We provide special designed MoSi2 elements according to customer needs, enabling an optimized element design for each particular application.Delivery time: 7days after receipt of deposit.
