UL MSDS New Pl982232 3.7V 700mAh Ncm Li-Polymer Lipo Battery
| Price: |
US $ 0.5-2/Piece |
| Min Order: |
1000/Piece |
| Pay Type: |
T/T,Western Union |
UL MSDS New Pl982232 3.7V 700mAh Ncm Li-Polymer Lipo Battery1.Major Technique Parameters:(Ref.)| 1)Normal Capacity: | 700mAh |
| 2)Min.Capacity: | 650mAh |
| 3)Normal Voltage: | 3.7V |
| 4)End of discharge Voltage: | 3.0V |
| 5)Charging Voltage: | 4.2±0.03V |
| 6)Internal Resistance: | ≤150mΩ |
| 7)Maximum Continuous Discharge Current: | 1.0C |
| 8)Maximum discharge instantaneous current : | 1.0C |
| 9)Operation Temperature Range(Discharge): | -20~60ºC |
| 10)Dimension:T9.8*W22*L32mm |
| 11)N.W: | about 13G |
2.Hot lipo battery models:
3.Major Features:| 1)Small Volume,Size can be customized,thinner,wider or longer |
| 2)High Capacity,single cell from 100-10000mAh. |
| 3)Rechargeable. |
| 4)Environmental Protection economy. |
| 5)Technique can be customized. |
| 6)High energy density. |
| 7)Fastest Charger |
| 8)Reliable and safety performance. |
| 9)Cycle life over 1000times ... |
4.Discharge Characters for reference:
5.Hot Applications:| 1)Wind Energy |
| 2)Notebook Computer |
| 3)E-tools |
| 4)Digital Camera |
| 5)Solar Energy Streetlight |
| 6)Model Aircraft |
| 7)E-Bike |
| 8)Communication Equipment |
| 9)Power Bank |
| 10)UAV |
| 11)Thermal Cloth |
| 12)Movable Lighting |
| 13)Digital Products |
| 14)RC |
| 15)E-Scooter |
| ... |
6.Major Production Procedure:
7.Major tests ensure high quality:| 1)Initial Performance Test |
| A.Open-Circuit Voltage |
| B.Internal Impedance |
| C:Min.Rated Capacity |
| 2)Cycle Life |
| 3)Leakage-Proof Test |
| 4)Vibration Test |
| 5)Drop Test |
| 6)Crush Test |
| 7)Short Circuit Test:BothºC20 and 60ºC |
| 8)Impact Test |
| 9)Forced Discharge Test |
| 10)Nail Pricking Test |
| ... |
8.Packing photos:
9.FAQ:| 1)Q:Can batteries OEM/ODM? | A:Lithium polymer battery and the battery pack can be customized according to customer requirements size, parameters, etc., please provide detailed specifications. |
| 2)Q:Warranty for batteries? | A:Usually 12months after production date(It will not covered by the warranty period if human damage) |
| 3)Q:Can i get samples | A:No problem.After our discuss details,samples can be arranged soon |
| 4)Q:What are your payment terms? | A:Small orders by Western Union,mass order by TT bank transfer |
| 5)Q:What's the delivery time for mass order? | A:Ensure quality first,if in stock,usually7-10working days;If customized for your requirements and consider qty,it'll need about 15-25working days. |
| 6)Q:When can i get the battery price? |
A:Quotation usually can be sent u within 24hrs,if urgently pls call us and yours can be priority |
Cindy H(Oversea Sales Manager)Zhuhai Angel Energy Technology Co.,LtdWeb: www.agmenergy.net agmbattery.en.made-in-china.comT:+86-0756-6889965 F:+86-0756-5239892M:+86-13727008595 Any other question pls feel free to contact us,thank you!
| Prod Model: |
AGM- PL982232 3.7V 700mAh |
| Voltage At End Of Discharge: |
3.0V |
| Charging Voltage: |
4.2 More or Less 0.03V |
| Internal Resistance: |
Less Than 150mΩ |
| Energy Ratio: |
High |
| Warranty: |
12months |
| Offer OEM: |
Ok |
| Major Anode Materials: |
Lco, Ncm, Nca, LiFePO4 etc |
| Charge&Discharge Current: |
0.5c |
| Operation Temp: |
-20-60ºC |
| Cycle Life: |
About 1000times |
| Type: |
Lithium-Ion Batteries |
| Usage: |
Emergency Light |
| Discharge Rate: |
Low Discharge Rate |
| Shape: |
Square Battery |
| Rechargeable: |
Chargeable |
| Nominal Voltage: |
3.7V |
Zhuhai Angle Energy Technology Co., Ltd is a professional engaged in rechargeable lithium-ion battery research and development, production and sales of the manufacturers. The company has nearly 17 years of experience in technology production, around the "team spirit, integrity management, and strive to innovation, market win-win" business philosophy and technical principles, battery products exported to the United States, Canada, Japan, Korea, Denmark, Britain, France, Bangladesh and so on more than 50 countries and regions and domestic Taiwan, Hong Kong and other markets, by the customer's support and trust. Daily production capacity high-capacity polymer lithium battery more than 200, 000pieces, Cylindrical batteriesmore than 100, 000pieces, E-cigarette battery 200, 000pieces, it's one of China's lithium battery industry major suppliers.
The lithium-ion battery: Cylindrical 18650 lithium battery, has passed UL, CE, CB and other international safety certification, through the SGS test, widely used in mobile DVD, laptop computers, mobile phones, Bluetooth products, MP3 / MP4, PDA, digital cameras All kinds of digital products and model aircraft, power tools, electric golf cars, E-toys, electric mower, electric scooter, Solar battery, RC, UAV, EV etc products.
The company has world-class R & D team and advanced production equipment, technology research and development in the same industry-leading position. We can according to the conventional requirements provided by customers, but also for the changing physical structure and special performance supporting design, from the material testing, design and production of batteries, protection circuit board design, to the finished product assembly, to provide a complete battery solution Program.
