| Markets: |
North America,Southeast Asia,Africa,Mid East |
| Application: |
Underground |
| Voltage: |
Low and Medium Voltage Cable |
| Current: |
DC & AC |
| Insulation Material: |
XLPE |
| Certification: |
CE |
| Brand: |
Jinshui |
Product Description
Description
1) Single Loose tube, filling jelly, non-metallic center strength member, water blocking tape, PE sheath
2) Compact structure, light weight, steel tape armored excellent crush resisitant performance
3) Excellent water proof layer, good moisture resistance
4) Suitable for aerial and duct
5) Apply toLong distance communication system, Local aera network system and Subscriber network system;
Application:
Adopted to Outdoor distribution.
Suitable for aerial .pipeline laying method.
Long distance and local area network communication.
Technical Parameters:
Total number of fiber cores |
2-12 |
Outer diameter (mm) |
7.8mm~8.5mm |
Cable Max unit weight (kg/km) |
65+ |
Allowable pull force (N) |
long-term |
600 |
|
short-term |
1500 |
Allowable crush strength (N/100mm) |
long-term |
300 |
|
short-term |
1000 |
Min bending radius (mm) |
static |
10 times of cable external diameter |
|
dynamic |
20 times of cable external diameter |
Application of temperature |
-40°C-60°C |
Optical Characteristics |
| Fiber Sort | Multimode | G.651 | A1a:50/125 | Graded-index fiber |
|
| A1b:62.5/125 |
|
| Singlemode | G.652(A,B,C,D) | B1.1:Conventional fiber |
| G.653 | B2: Zero dispersion shifted |
| G.654 | B1.2 :Cut-off wavelength shifted |
| G.655 G657 | B4: Main technical data for positive
dispersion shifted single-mode fiber |
Established in 1984, Henan Jinshui Cable Group Co., Ltd. specializes in design and manufacture of various kinds of wires and cables. Our company's headquarters is located in Zhengzhou City of Henan Province, a famous city with convenient transportation in China.
Our company is in charge of 23 domestic sale companies and one trade company, Zhengzhou Jin Hang High-Tech Co., Ltd., mainly responsible for overseas market. There are 638 staff members in the factory, including 18 experienced engineers, 52 lab assistants and 568 workers. The capital asset reached USD10, 507, 000. We have various advance product lines and equipment, including 180 sets for producing use and 40 sets for testing and measurement use. Our product can perfectly meet requests of different standards, for example GB, IEC, BS and ASTM. We also have some ability to satisfy special need of customers. The annual product capacity of cables and wires of our factory is more than 10, 000, 000 kilometers.
As one of the leading manufacturers of cable industry in Henan Province, we obtained certificate of ISO9001 in 2003. All cables of colliery have gotten the certificate of safety for colliery. Our fire retardant cables are approved with the certification of proof products, and most of them met the standards of China Compulsory Certification (CCC). Moreover, we have been already licensed to enter the "Supplier of the China Government Procurement" by the government.
For years, we are keeping providing products with high quality and good service. Our cables and wires are widely used in the construction of buildings airports, power transportation, urban and rural power network reformation and other main projects. Both of products and the factory are greatly commended by customers. Also, we really highly value the overseas market. Our factory has the qualification to export independently which is awarded by Chinese government. The main products of our company have been exported to Africa, Australia, America, Italy, Singapore and other Asian countries. We insisted that pay adequate attention to every customer's request. We insist on our principle of "Good Quality Results Trust and Honesty Makes Success". We sincerely welcome you to touch with us and visit us.
