Zemic Column Structure Load Cell Bm14G

Name: Zemic Column Structure Load Cell Bm14G
Brand: all-electronics-online.com
SKU: 732110142
Availability: InStock
Rating: 4.6 (61 reviews)

Price:	US $ 1-100/Piece
Min Order:	10/Piece
Pay Type:	L/C,T/T,Western Union,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	BM14G
Capacity:	10t to 50t
Pattern:	Column Structure

Product Description

Stainless Steel Zemic Column Structure Load Cell BM14G

Description:
1. BM14G load cells are available in the capacities 10t to 50t . And the customized capacity is available by request.
2. Strainless steel construction,hermetically welded,oil-proof, waterproof and anti-corrosive gas and medium making it lightning protected in all kinds of environment.
3. Column structure,anti-reversal design,good self-aligning ability, suitable for electronic platform scales,automobile testing facilities, hopper scales and other electronic weighing device

Important Features:
1. High accuracy.
2. Stainless steel construction.
3. Easy installation and reliable performance.
4. With OIML approval

Specifications:

Capacity	t	10/20/30/40/50
Accuracy class		C2	C3	C4	A5S	A5M
Approval			OIML R60 C3
Maximum number of verification interval	n max	2000	3000	4000	5000	5000
Minimum load cell verification interval	v min	Emax/5000	Emax/10000	Emax/14000	Emax/15000	Emax/15000
Combined error	(%FS)	≤±0.030	≤±0.020	≤±0.018	≤±0.018	≤±0.026
Creep	(%FS/30min)	≤±0.024	≤±0.016	≤±0.012	≤±0.012	≤±0.017
Temperature effect on sensitivity	(%FS/10ºC)	≤±0.017	≤±0.011	≤±0.009	≤±0.009	≤±0.013
Temperature effect on zero	(%FS/10ºC)	≤±0.023	≤±0.015	≤±0.010	≤±0.010	≤±0.014
Output sensitivity	(mv/v)	2.0 ± 0.02
Input resistance	( Ω )	700 ± 7
Output resistance	( Ω )	703 ± 4
Insulation resistance	(M Ω )	≥ 5000(50VDC)
Zero balance	(%FS)	1.0
Temperature, compensated	( ºC )	-10~+40
Temperature, allowed	( ºC )	-35~+65
Excitation, Recommended	(V)	5~12(DC)
Excitation,Max	(V)	18(DC)
Safe overload	(%FS)	150
Ultimate overload	(%FS)	300

Gromy Scale Co., Ltd. is a professional manufacturer and exporter committed to weighing equipments research and manufacture. We are located in beautiful Hangzhou, with convenient transportation access. We provide wide range of equipment scale, weighing indicator, load cell, balance, household scale, body scale, commercial scale floor scale, truck scale, test weights and other instruments. We have more than 10 years experience in this area, all of our products comply with international quality standards and are greatly appreciated in a variety of different markets throughout the world.

As a result of our high quality products and outstanding customer service, we have been providing our products to more than 50 countries and areas, reaching Europe, South America, North America, Asia-Pacific and Africa markets.

With the vision of "improving everyday", Gromy Scale will continue to provide the high standard and most cost-effective weighing products for the majority of weighing companies all over the world.

If you are interested in our existing models as well as OEM customized products, we warmly welcome your business inquiry; We are here to serve you best.

We always welcome your visit and inquiry!
