1-10kVA Single Phase Pure Sine Wave Online UPS with Double Conversion
Price: |
US $ 119/Piece |
Trade Terms: |
FOB,CFR,CIF |
Min Order: |
1/Piece |
Pay Type: |
T/T,Western Union,Money Gram |
Prod Model: |
EX series 1-10kva |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Voltage Range: |
1-10kVA |
Power Range: |
0.8-8kw |
Input Voltage: |
110/115/120VAC or 220/230/240VAC |
Output Wave Form: |
Pure Sine Wave |
Output Voltage: |
110/115/120VAC or 220/230/240VAC |
Output Power Factor: |
0.7/0.8 |
Communications: |
Intelligent RS232 Serial Port/Snmp/USB |
Frequency: |
50/60Hz |
Display: |
LCD/LED |
Battery Type: |
Sealed Free Maintenance Lead Acid Battery |
Phase: |
Single Phase |
Type: |
On-line |
Protection: |
Overload, Short Circuit, Overcurrent, Overvoltage |
Standby Time: |
According to The Battery Bank |
Brand: |
Zlpower |
Product Description
1-10kva Single Phase Pure Sine Wave Online UPS With
Double Conversion
1kva 2kva 3kva 6kva 10kva online ups
Main Features
*Wide input voltage range, Zero transfer time.
*Excellent Protection against over voltage, over load, over current, over charge and so on.
*Input L and N lines reverse wiring detection, Auto start when AC back.
*DC start function, Input PFC revise function.
*Humanization bypass output can be adjustable.
*Smart RS232 communication with monitoring software.
*Intelligent slot available for AS-400 Dry contact and SNMP card Remote control.
*Available to work with generators.
*Lightning, surge, short circuit, Network/fax/modem surge protection.
Application
Specially designed for servers,data-center critical network devices,senstitive electronic equipment,telecom,bank,hospital,bureau,traffic,public security,ATM and so on.
UPS Model | EX1K | EX1KL | EX2K | EX2KL | EX3K | EX3KL |
Capacity | 1000VA/800W | 2000VA/1600W | 3000VA/2400W |
Input | Voltage | (115~300)VAC |
Frequency | 46~54Hz/56~64Hz |
Output | Voltage | 220/230/240 (1± 1%) VAC |
Frequency | 50/60Hz (Adjustable) 50Hz AC Mode: Follow AC Mode (AC Range 46~54Hz), Battery Mode: 50Hz (1± 0.2%) 60Hz AC Mode: Follow AC Mode (AC Range56~64Hz), Battery Mode: 60Hz (1± 0.2%) |
Output Wave Form | Sine Wave |
Back-up Time | Full Load | ≥ 5′ | Depends on the capacity of the external battery bank | ≥ 9′ | Depends on the capacity of the external battery bank | ≥ 5′ | Depends on the capacity of the external battery bank |
Half Load | ≥ 14′ | ≥ 21′ | ≥ 15′ |
BatteryNominal DC Voltage | 36VDC | 96VDC |
Transfer Time | 0ms |
Overload Capacity | 110%~150% maintain 30s then turn to bypass output, over 150% maintain 300ms |
Communications | RS-232+Intelligent Slot |
Environment | Temperature | 0~40 Centigrade |
Humidity | 15%~90% |
Dimensions (W*D*H) mm | 145*400*220 | 192*460*340 |
Net Weight (Kg) | 14 | 7 | 34 | 13.5 | 34.5 | 14 |

About ZLPOWER
Founded in 2007, Shenzhen ZLPOWER Electronics Co., Ltd. (ZLPOWER for short) is a key hi-tech enterprise in state "Torch Plan, " integrating science, industry, trade, and investment into a whole. It has registered capital of RMB 10million, covering a floor area of 2000sq. M, and owning assets of RMB 30 million.
As a large-scale enterprise group with total assets exceeding RMB 30 million, it currently employs more than 300 staff, operates R & D institutions, 10 products lines, and 8 overseas branches and offices for sales and service.
Also as a professional uninterruptible power supply manufacturer in Shenzhen, China, ZLPOWER mainly produce high frequency online UPS, computer PC UPS, rack mount online UPS, low frequency Industry three phase UPS, UPS Inverter, solar inverter, solar charger controller, Solar/UPS Battery and other related products.
In ZLPOWER, we are strictly on quality inspections. We implement strict IOC, IPQC, FQC, OQC, QA, and other quality control measures in every process according to ISO9001, including to raw materials selection, production, package, and shipment.
Thus, we are ISO9001: 2008 and SGS certificated, and all our UPS, Inverter power supply products have been approved by CE (LVD/EMC), UL tests. As a result, they are popular among our customers from Italy, Germany, South Africa, Egypt, Mozambique, Nigeria, UAE, Ukraine, Russia, Uzbekistan, Philippines, Chili, Peru, Brazil, Mexico and more.
ZLPOWER is looking for agent worldwide to distribute our quality UPS system, Inverter power and solar products to their local markets. Any interests please welcome to contact us today and look for best power solution.
