1.2V Low Discharge Rate Battery for UPS 110V or 220V

Name: 1.2V Low Discharge Rate Battery for UPS 110V or 220V
Brand: all-electronics-online.com
SKU: 819070785
Availability: InStock
Rating: 4.8 (93 reviews)

Price:	US $ 129-145/Piece
Min Order:	100/Piece
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	GN300
Type:	Ni-CD Battery
Usage:	Lighting
Nominal Voltage:	1.2V
Discharge Rate:	Low Discharge Rate
Shape:	Square Battery
Rechargeable:	Chargeable

Product Description

DataSheet

The data sheet of GN300=KPL300 as follow:

1.cell type:KPL300 (Low rate dicharge battery with long discharge time)

2.rated capacity:300AH

3.nominal voltage:1.2V

4.container :,PP

5.delivery with dry battery . electrolyte(KOH+LIOH+DISTILLED WATER)

Application:

1)KPL ,KPM,KPH,KPX batteries are designed for a wide variety of stationary indstria applications

such as power back-up,engine starting an bulk energy sorage.

See following detailed application tables.

Series	Discharge rate	Plate type	Application areas
KPX	Ultra High rate	Sintered plate	AGV; starting power; operating power of electrical system;railway, etc.
KPH	High rate	Pocket plate	Staring power; UPS; etc.
KPM	Medium rate	Pocket plate	Starting power; operating power of electric system; UPS etc.
KPL	Low rate	Pocket plate	Emergency lighting; communication; vessels; backup power of locomotive; energy storage of wind and solar power generation; etc.

2)KPH TYPE (High Discharge Rate Cell)
KPH Series high rate Nickel Cadmium battery is particularly suitable for high discharge rate applications less than one hours, such as UPS, switchgear tripping and closing, etc.

KPM TYPE (Medium Discharge Rate Cell)
KPM Series medium rate nickel cadmium battery is made of pocket plates. The battery is suitable for medium discharge rate applications (between 30 minutes to 5 hours) such as railroad DC power sources, UPS, gas turbine control, etc.

KPL TYPE (Low Discharge Rate Cell)
KPL Series low rate nickel cadmium battery is made of pocket plates. The battery is designed for general purpose and standby applications such as lighting on trains, operation of circuit breaker, etc.

HengMing Group is a high-tech company in Henan with more than $10 million in capital 30 years of experience. Our factory covers an area of 16, 000 square meters manned by 280 workers including 10 professional engineers. Hengming-branded products are popular in mainland China.

We offer Ni-CD batteries in KPL, KPM, KPH, KPX series. They are widely used in the Railway signaling, Alarms, Telecommunications, UPS, DC power sources, Power plant, Engine starting, Emergency back-up power, etc.

We offer Ni-Fe solar batteries in TN series. They are widely used for Solar energy, On-gird off-gird PV power system, specially suitable for solar photovoltaic applicationsrenewable energy storage applications.

We offer Ni-MH pocket type batteries, capacity range from 10Ah to 1200Ah.

HengMing's products have been exported to more than 20 countries and regions including Singapore, South Korea, Malaysia, the United States, Spain, Iran, Mexico, Pakistan, Bangladesh, Indonesia, Poland, Turkey, etc
