Fuan Tongbo Electrical Machinery Co., Ltd. >> 1.5HP 1.1kw Jy Series Induction Motor

1.5HP 1.1kw Jy Series Induction Motor

1.5HP 1.1kw Jy Series Induction Motor
Price: US $ 80/Piece
Min Order: 100/Piece
Pay Type: L/C,T/T,D/P,Western Union
Prod Model: JY2A-2
Application: Industrial
Operating Speed: Constant Speed
Number Of Stator: Single-Phase
Rotor Structure: Winding Type
Casing Protection: Protection Type
Starting Mode: Auto-induction Voltage-reduced Starting
Species: Jy Series Single-Phase
Brand: Tongbo

Product Description

INTRODUCTION
JY series single-phase capacitor start induction motor is suitable for any awhere a larger starting torque and the starting current to be limitedare required,and is used as driving motor of air compressors,refrigerators,medical apparatus and other small machines in which full-load starting is demanded.These series motors are totally enclosed fan-cooled 2.The frame are made of cast iron or cast aluminium according to the requests.
OPERATING CONDITIONS
Ambient temperarture:-15ºC<θ<40ºC
Rated voltage:110V,115V,120V,220V,230V,240V
Rated frequency:50HZ or 60H
Protection class:IP44,IP54
Insulation class:B,F
Cooling method:ICO141
Duty:S1(continuous)




FUAN TONGBO ELECTRICAL MACHINERY CO. Ltd. was founded on July 1st, 2009 in FU'AN city, "the city of electric machinery", as an export oriented manufacturer of Electric Motors, AC Generators and Generator Sets. We specialize in R&D, production, sales and customer service of said items and pride ourselves as professionals in related area.

Our own brand "TONG BO" consists of different models of motors listed as below:

1. Three phase asynchronous motor - Y series, Y2 series, AEEF series etc.

2. Single phase asynchronous motor --YC series, YL series, JY series

3. Aluminum Casing three phase asynchronous motor --MS series

4. Aluminum Casing single phase asynchronous motor--MC series, MY series, ML series

"TONGBO" Brand AC generator models are listed as below:

1. Single phase ST series with brush

2. Three phase STC series with brush

3. Copy Stamford TBS brushless series

We also have generator sets like CUMMINGS series generator set, YUCHAI series generator set, WEICHAI series generator sets etc.

Throughout design, manufacturing process, material selection, production, equipment testing, quality control, we make every endeavor to ensure our production is in strict accordance with ISO9001 Quality Management System in order to yield high quality products.

Our products travel widely from South-east Asia to as far as Middle-east, Africa also US and European countries. TONGBO has won a high admiration and is widely trusted at home and abroad.

Our goal is to build "TONGBO" into a world-renowned brand. In order to achieve that, we promise to run an honest business by putting quality and customer satisfaction as our top priorities. With "Honesty, Team-spirit, Responsibility, Hard-work and Gratitude "as essence of our corporate culture, We shall continue to provide our valued customers with high quality products and professionalism to the best of our abilities.
