1.8mm SC APC Fiber Optic OM4 Multimode Aqua Patch Cable

Name: 1.8mm SC APC Fiber Optic OM4 Multimode Aqua Patch Cable
Brand: all-electronics-online.com
SKU: 691358191
Availability: InStock
Rating: 4.9 (21 reviews)

Price:	US $ 4-30/Meter
Min Order:	1/Meter
Pay Type:	L/C,T/T,Western Union,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	7383
Cable:	SM
Connector:	SC
Fiber Type:	Singlemode
Color:	White
Insertion Loss:	0.3dB
Length:	10FT
Application:	Probe
Type:	Single-mode Fiber
Connection Structure:	SC-SC
Certification:	CCC

Product Description

1.8mm SC APC Fiber Optic OM4 Multimode Aqua Patch Cable

Fiber optic cables are used in applications where distance and speed are at a premium. Compared to coaxial and twisted pair cables, fiber optic cables have the capability to transmit and receive data at vastly greater distances and speeds. SINO this kind of Curl Fiber patch cord is retractable and usable in household wiring and wiring for movable parts of machines.The curl length(cm) and total length can be customed according to the customer's requirements in our manufacturer. The meters is point to the length of the cable after straightening. Bending diameter, Bending laps could be customized according to the total length you required. Copper is becoming obsolete as Fiber Optics are taking over. We as a factory provides you quality fiber optics at aggressive prices.

Features

RoHS Compliant;
Standard & custom configurations;
Meets Telecordia-GR-326-CORE standards;
Easy installation;
Environmentally stable;
Low insertion loss, high return loss;
Ultra low back reflection;
For 3.0mm, 2.4mm, 2.0mm jacket or 900um buffer;
Single mode fiber: ITU - T G. 652D;
Multi mode fiber: ITU - T G. 651;
Fiber Min. Bending radius: 10D (Static).

Applications

It can stretch several times without deteriorating the optical characteristics;
It can adjust length of cable;
It is durable enough to be used for movable parts of machines and as a connecting cord for instruments;

Specification & Parameters

Fiber Type		SM		MM
Connector Tytpe		MTRJ	D4, FC, SC, ST, LC, E-2000, MU	D4, FC, SC, ST, LC, E-2000, MU	MTRJ
Insertion Loss (Typical)		≤0.4dB	≤0.2dB	≤0.4dB	≤0.2dB
Insertion Loss (Max)		≤0.5dB	≤0. 3dB	≤0.3dB	≤0.5dB
Return Loss (Typical)	PC		≥50dB
	APC		≥65dB
	UPC		≥55dB	≥55dB
Mating Durability	≤0.2dB
Durability	≥1000 times
Storage Temperature	- 40ºC~+ 85ºC

Dimensions

Cable Diameter	1.8mm
Jacket Color	White
Connector 1	DIN
Connector 2	E2000
Polishing Type	APC
Fiber Type	G657A1, SM, Single-mode
Cable Length	1m / 10ft; or customized
Total Fibers, quantity	2

Environmental Specifications

Environmental Space	PVC
Operating Temperature	-10 °C to +60 °C (+14 °F to +140 °F)
