| Prod Model: |
1 Channel Transceiver |
| Transmission Wavelength: |
1310nm/1550nm |
| Video Connector: |
BNC Female |
| Data Channel: |
1 or 2-Way |
| HS Code: |
8542900000 |
| Connector: |
Simplex FC |
| Type: |
Fiber Transceiver |
| Wiring Devices: |
Integrated Wiring |
| Certification: |
RoHS |
| Condition: |
New |
Product Description
1 Channel Video and Reverse Data Fiber Transceiver
Detail:
This series of Digital Optical adopt all-digital communication, can be simultaneously transmitted on a single fiber 1 forward video, 1 or 2 channel reverse RS485/422 data. Video adopt non-compressed digital video encoding, and video formats compatible with PAL, NTSC, SECAM formats, provides broadcast-level image quality. High-quality video effects to meet the various needs of users, plug and play design makes installation simple, without the need for on-site commissioning, can work in different environments, prolonged stability. Power and other parameters of the LED status indicator lights that monitor the system operation. Product lightning proof design, to ensure the stability of equipment, no electromagnetic, no radio frequency interference, no ground current. The product has both high-quality digital transmission, the advantages of long-distance, but also has the advantage of low prices, is ideal for long-distance fiber-optic video transmission equipment.
Features:
Fully-digital no compression, broadcast, fiber optic transmission
Ultra-optical dynamic range, without adjust when use it.
Compatible with PAL, NTSC, SECAM and other formats of video transmission
RS232/485/422 data communication
Three lightning proof protection
Industrial design, high reliability, can meet the harsh environmental
Automatic power adjustment, automatic temperature compensation circuit, automatically restored overload protection.
Full Surface Mount Technology
Monitoring can use standard 19 "4U chassis, the remote uses a small desktop chassis
Monitor side chassis can be inserted eight cards, network cards can be inserted to achieve centralized management
Remote optical transceiver can be hung on the wall
| part number | product name | specification | Extensible specification | Masurement | Unit price/USD |
| VC1010 | 1-Channel Video optical converter | 1 Way vedio, FC / ST interface optional; Transmission Distance 20KM. | | pair | 61.94 |
| VC1010-1D | 1 way vedio, 1 way reverse data optical transceiver
| 1 way RS485 reverse data | pair | 67.75 |
| VC1020 | 2-Channel Vedio Optical Converter | 2 way video, FC/ST interface optical; Transmission Distance 20KM. | | pair | 75.49 |
| VC1020-1D | 2 way vedio, 1 way reverse data Optical converter | 1 way or 2 way RS232/485/422 data optional | pair | 81.29 |
| VC1040 | 4 Channel Video Optical Converter | 4 way vedio, FC/ST Interface optical; Transmission Distance 20KM. | | pair | 94.84 |
| VC1040-1D | 4 way vedio, 1 way reverse data Optical Transceiver | 1 or 2 way RS232/485/422 data optional | pair | 100.65 |
| VC1040-1Dxx | 4 way video, 1 way reverse data, 1-4 way Audio or Phone or Switch optical transceiver
| 1 or 2 way RS232/485/422 data optional; 1-4 way vedio/phone/Switch optical | pair | updating
|
| VC1080 | 8-Channel Vedio Optical Converter | 8 way vedio, FC/ST Interface optional; Transmission Distance 20 KM. | | pair | 108.39 |
| VC1080-1D | 8 way vedio, 1 way reverse data optical transceiver | 1 or 2 way RS232/485/422 data optional | pair | 114.20 |
| VC1080-1D1E | 8 way vedio, 1 way reverse data, 1 way Ethernet Optical Converter | 1 or 2 way RS232/485/422 data optional; 1 way 100M BASE-T ethernet | pair | updating |
| VC1080-1Dxx | 8 way vedio, 1 way reverse data, 1-8 Channel Switch Optical Transceiver | 1 or 2 way RS232/485/422 data optional; 1-8 way vedio/phone/Switch optical | pair | updating |
