10 Foot MPO to MPO Fiber Optic Cable 8 Aqua Trunk OFNR Plenum Cable Polarity B

Name: 10 Foot MPO to MPO Fiber Optic Cable 8 Aqua Trunk OFNR Plenum Cable Polarity B
Brand: all-electronics-online.com
SKU: 811645685
Availability: InStock
Rating: 4.6 (99 reviews)

Price:	US $ 8.6-9/Meter
Min Order:	1/Meter
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	PN-001
Fiber Type:	Multimode; Singlemode
Cable Color:	Aqua
Fiber Count:	12
IR:	>60dB
IL:	>0.35dB
Polishing Ferrule:	PC, Flat
Cable Material:	PVC
Application:	Sensor
Type:	Multi-mode Fiber
Certification:	ISO9001
Connection Structure:	MPO-MPO
Brand:	PUNO

Product Description

10 Foot MPO to MPO Fiber Optic Cable 8 Aqua Trunk OFNR Plenum Cable Polarity B

In the past decades, the network speed has a great leap from 10Mbit/s in 1983 to today's 40 / 100 Gbit/s. Thus new technologies have been developed to support the new transmission rate. Of which MPO technology with multifiber connector make the migration to 40 / 100 Gigabit Ethernet easier and more efficient, as it offers ideal conditions for setting up high-performance data networks in data centers to achieve greater bandwidth and handle future requirements. This article will briefly introduce the basics of MPO technology and its utilization in 40G Ethernet.

Application:

√ Multiple 100G channels;
√ CFP to CFP direct connect;
√ Distribution area connections;
√ 100G patch cord connection;
√ 100G extender cabling.

Feature:

√ High Density Fiber Management Solution;
√ 8 or 12 Strands per connecter;
√ Mates to all MTP or MPO connectors;
√ Precision polished for minimum insertion loss and back reflection;
√ Push / Pull Connector Mating;
√ Plenum Rated Cable;
√ Fanouts to discrete simplex connecters available;
√ 50 and 62.5 micron core fiber available.

Environmental:

Operating Temperature Rating	-5ºC to +70ºC
Storage Temperature Rating	-40ºC to +70ºC

MPO Connector:

MPO Multimode (OM3 and OM4) 24 fibre Connector
Connector Housing	Aqua
Ferrule	MT ELITE
Typical Insertion Loss	0.10 dB (average)
Maximum Insertion Loss	0.35 dB (Max)
MPO Singlemode (OS1/ OS2) 24 fibre Connector
Connector Housing	Yellow
Ferrule	MT ELITE APC
Typical Insertion Loss	0.10 dB (average)
Maximum Insertion Loss	0.35 dB (Max)
Return Loss	> 60 dB

Cable Technical Parameters:

Cable Count	Out sheath Diameter(mm)	Weight(kg)	Minimum allowable Tensile Strength (N)		Minimum allowable Crush Load (N/100mm)		Minimum Bending Radius (mm)		Storage temperature (°C)
Cable Count	Out sheath Diameter(mm)	Weight(kg)	Short term	Long term	Short term	Long term	Short term	Long term	Storage temperature (°C)
2	3.5*2.5	13	500	100	500	100	20D	10D	-20ºC+60ºC
4	3.5*2.5	13	500	100	500	100	20D	10D	-20ºC+60ºC
6	4.0*2.5	15	500	100	500	100	20D	10D	-20ºC+60ºC
8	4.5*2.2	15	500	100	500	100	20D	10D	-20ºC+60ºC
12	4.8*2.2	17	500	100	500	100	20D	10D	-20ºC+60ºC
