1000va SVC Single Phase Voltage Regulator Automatic AC Voltage Regulator

Name: 1000va SVC Single Phase Voltage Regulator Automatic AC Voltage Regulator
Brand: all-electronics-online.com
SKU: 809775635
Availability: InStock
Rating: 4.8 (94 reviews)

Price:	US $ 13.89-246.44/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	SVC-1000
Input Voltage:	140V-250VAC ,110V-250VAC
Efficency:	> 90%
Relative Humidy:	Less Than 90%
Output Voltage:	220V±3%
Current Type:	AC
Phase:	Single Phase
Usage:	SVC
Frequency:	50-60 Hz
Brand:	Honle

Product Description

1000va SVC single phase voltage regulator automatic ac voltage regulator

Relavant models

SVC-500VA	SVC-1000VA	SVC-1500VA	SVC-2000VA
SVC-3000VA	SVC-5000VA	SVC-5000VA(DOUDLE COILS)	SVC-7500VA
SVC-10000VA(VERTICAL)	SVC-15000VA	SVC-20000VA	SVC-30000VA

Products Specification

Name/Model	Voltage stabilizer/SVC-1000va
Phase	Single
Input voltage	140V-250VAC ,110V-250VAC or 70V-250VAC
Output voltage	220V±3%
Under-voltage protection	set arcording to users requirement, generally

Over-voltage protection	256V±4V(according to users requiremnts,generally not set
Efficency	> 90%
Regulating speed	< 1S(when input voltage varies 10%)
Temperature-rise	< 60°C(under full-load condition)
Frequency	50~60Hz
Waveform distortion	No additional distrortion
Max rated output current	0.5KVA 2A, 1KVA 4A, 1.5KVA 6A, 2KVA 8A, 3KVA 12A,
5KVA 20A,10KVA 40A, 15KVA 60A, 20KVA 80A, 30KVA 120A
Ambient temp	-5°C~+40°C
Relative humidity	Less than 90%

Honle Electric Co., Ltd is the manufacturer specialized in producing industrial electrical products. It has three factories, the first one produces power supply, the second one produce power transformer, the third one produces complete plants and equipment. As a member of China Power Supply Society, since its foundation, the company has been insisting on the theoretic guideline of "science &technology is the first productive force" and holding up brand strategy as the guide, relying on forward understanding about power supply technology, perfect craft and unwearied pursuing to quality, we can show top quality power supply products, and set up fine image in Chinese market and overseas market.

Up to now, Honle has the modern workshops and advanced production devices. Besides, the company always introduces technology positively, reforms craft continuously, devotes to researching and developing the voltage stabilizer, regulator and power supply, precise pureness power supply, providing, marketing for products. The company always do researching and developing the stabilized voltage power supply, precise pureness power supply, providing marketing for products. In addition, the company tries to find excellent administrators and technical talents. After just a few years of continuous efforts, Honle has been improved on the aspect of varieties, production scale, management mode. So products manufactured by Honle have reached advanced technical level, they are not only popular with a great many customers in China, but also in foreign countries.

The products of our company have been approved by Shanghai Quality Supervision & Inspection Institute, and insured by PICC company. Honle insists on the quality of survival, innovation and development all the time, and it has passed ISO9001 quality management system certification. Relying on rich economic strength, fine production engineering, innovating management mode, we can dare to meet kinds of challenges from China entering WTO. That is helpful for establishing reinforced foundation of international business.
