1000W 2000W 3000W 4000W 5000W 6000W 7000W 8000W PV System Power Inverter off Grid Pure Sine Wave Inverter

Prod Model:	GS1000-8000W
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Capacity:	1000W 2000W 3000W 4000W 5000W 6000W 7000W 8000W
Protection:	Short Circuit, Overvoltage, Overcurrent
Wave Form:	Pure Sine Wave
Wide Input Voltage Range:	80-270VAC
Peak Power:	3 Times of Rating Power
Power Factor:	0.9-1.0
Output Voltage:	110/220VAC
Optional Function:	DC/AC Priority Funcion, DC Restart Function etc
Phase:	Single
Brand:	Zlpower

Product Description

1000-8000W PV System Power Inverter Off Grid Pure Sine Wave Inverter

1000-8000W Wide Input Range   12/24/48V dc


>>Main Application

1> Transport equipments: military vehicle, police car, Medical ambulance, ship, traffic lights etc.
2> Industrial equipments: solar energy system, wind power, metal halid lamp, high voltage sodium lamp, etc.
3> Office equipments, computer, printer, display apparatus, duplicator, scanners, digital camera, digital pickup camera, etc.
4> Home equipments: cleaner, fan, lighting, electric cutter, sewing machine, etc.
5> Kitchen appliances: microwave ovens, induction cooker, refrigerator, etc.
6> Electric tools: electric saw, driller, muller, sandblasting machine and punching machine, lawn mower, air compressor, etc.
7> Electronic field: TV, DVD, video games, power amplifiers, auto equipment, monitoring equipment, terminal equipment, server, intelligent platform, satellite communication equipment, etc.





>>Key feature

1.GS pure sine wave inverter charger 1000w-8000w
2. LED and LCD display
3. 3 times peak power
4. Built-40A MPPT Solar Charger Controller
5. Enhance AC Charger to 20A/35A/50A/70A/90A(According to the inverter model)
6. Selectable input voltage range for home appliances and personal computers
7. Configurable AC/Solar input priority via LCD setting
8. Compatible to mains voltage or generator power
9. Overload and short circuit protection
10. Smart battery charger design for optimized battery performance
11. Dry contact function
12. Optional remote panel available


 Photos


>>Good Functions

1. Optional DC/AC priority function
2. Wide AC Input Voltage Range
3. Optional Battery types and Performance
4. Adjustable charging current
5. Built-in MPPT Solar Charge Controller
6. PV Port For connecting Solar Panel directly





>>Usage

Please assure the Inverter Power is switch off before connection of the battery. Please connect the anode to the red interlink, and cathode pole to the black interlink, be assure of the steady connection, then connect to the load, after all these done, press the turn on button to start inverter.
1. Do not connect the anode and cathode in wrong places.
2. Use in ventilated and dry environment.
3. When output in high voltage, please DO NOT operate with power on.
4. Turn on the Inverter when short circuit is not allowed.
