1000W Power Converter Pure Sine Wave Solar Inverter with Customized Output Socket
| Price: |
US $ 35-50/Piece |
| Min Order: |
100/Piece |
| Pay Type: |
L/C,T/T,Western Union,Paypal |
Product Description
Protection Function:-Low voltage alarm & Shutdown·Over voltage protection·Overload protection·Over temperature protection·Short circuit protection·Reverse Polarity protection·Soft start·Auto.reset after being in protected·Grounding protection | User Guide |
| Application | Wattage | Inverter Wattage |
| 150W | 300W | 500W | 800W | 1000W | 2000W | 3000W | 4000W |
| Mobile phone | 5W | √ | √ | √ | √ | √ | √ | √ | √ |
| 12 inch color television | 16W | √ | √ | √ | √ | √ | √ | √ | √ |
| Video games console | 20W | √ | √ | √ | √ | √ | √ | √ | √ |
| Electric light | 25W | √ | √ | √ | √ | √ | √ | √ | √ |
| Satellite TV receiver | 30W | √ | √ | √ | √ | √ | √ | √ | √ |
| CD or DVD player | 30W | √ | √ | √ | √ | √ | √ | √ | √ |
| HiFi stereo 4-Head VCR | 40W | √ | √ | √ | √ | √ | √ | √ | √ |
| Guitar amplifier (at average volume) | 40W | √ | √ | √ | √ | √ | √ | √ | √ |
| Stereo system (at average volume) | 55W | * | √ | √ | √ | √ | √ | √ | √ |
| Electric fan | 55W | √ | √ | √ | √ | √ | √ | √ | √ |
| Notebook | 60W | √ | √ | √ | √ | √ | √ | √ | √ |
| GE 9 inch color TV/radio/cassette | 65W | √ | √ | √ | √ | √ | √ | √ | √ |
| 19 inch color TV | 80W | √ | √ | √ | √ | √ | √ | √ | √ |
| 20 inch VCR combo | 110W | √ | √ | √ | √ | √ | √ | √ | √ |
| 27 inch color TV | 170W | | √ | √ | √ | √ | √ | √ | √ |
| Stereo amplifier | 250W | | * | * | √ | √ | √ | √ | √ |
| Small-medium printer | 350W | | | * | * | * | √ | √ | √ |
| Home theater system | 400W | | | * | * | * | √ | √ | √ |
| Power drill | 400W | | | √ | √ | √ | √ | √ | √ |
| Rice cooker | 500W | | | √ | √ | √ | √ | √ | √ |
| Small coffee machine | 600W | | | | * | * | √ | √ | √ |
| Refrigerator | 750W | | | | * | * | * | √ | √ |
| Small microwave oven | 800W | | | | * | * | * | √ | √ |
| Toaster | 1000W | | | | | * | * | √ | √ |
| Hair dryer | 1000W | | | | | | √ | √ | √ |
| Full size microwave oven | 1500W | | | | | | * | * | * |
| Electric kettle | 1800W | | | | | | √ | √ | √ |
| Induction cooker | 2000W | | | | | | * | * | * |
| washing machine | 2500W | | | | | | | * | * |
| Air conditioner 16000BTU | 2500W | | | | | | | | * |
| Air compressor 3HP | 2800W | | | | | | | | * |
| Heavy duty power tools | 2800W | | | | | | | | * |
| Air conditioner 22400BTU | 3500W | | | | | | | | * |
| Note: For those starred models, pure sine wave inverters are preferred. |
| SNC-300-S | DC 12V/24V TO AC 230V | 12 | 60*28*40 | 14 | 15.4 |
| 300W continuous power inverter |
| 600W Peak Power |
| No Load Curent Draw: < 0.5A |
| Efficiency: > 87% |
| Pure sine wave output |
| Input Voltage : 10V-15V/21V-30V |
| Frequency: 50HZ+2 |
| Low battery alarm:10.5V+ 0.3V,21+0.5V |
| Low battery shut down: 10V+0.5V 20V DC±0.5V |
| Over voltage shut down: 15.5V+0.5V or 30.5V+0.5V |
| Over load shut down :360W over 10 seconds |
| Over heating shut down>75ºC |
| Over Thermal :shut down the output |
| Short Circuit: fuse |
| Working Temperature: Between -10ºC and +50ºC |
| Working Humidity: 20%~90%RH non-condensing |
| Storage Temperature : Between -30ºC and +70ºC |
| Dimension: 150*130*52mm |
| Weight:1.2+0.2KG |
Founded in 2005, SUNKAX Technology Limited is a leading manufacturer and exporter for clean power, such as solar inverter, step up/down voltage transformers, consumer electronics (travel charger adaptors, USB Chargers, output power distribution board, etc. ).
Our products are exported to different countries all over the world, be popular in market for high quality, attractive packing, favorable price, and also excellent service.
With a 19, 000 factory, 8 production lines and over 150 well-trained workers, we turn out 90, 000 units monthly. All our products for export must strictly pass IQC inspections on critical components, 100% online testing, under loading and burn-in testing
SUNKAX has been a pioneer of technology. Back in 2005, we explored the key technology of aluminum transformer production and became the first aluminum transformer supplier
In the automatic voltage regulator field, we developed our own high performance MCU controlled circuit and have obtained several registered patents for our products. We developed air-conditioners stabilizers the best solution to meet your demand.
In inverter/UPS field, We are the 1st to invent toroidal inverters. Which have outstanding advantage of low idle current, low electromagnetic interference, long back-up time and high efficiency. Equipped 32-bit speed CPU control with accurate detection and unique C. R. G. O toroidal transformers, including our solar integrated inverters, all core technology are developed by own R&D team, which makes us one of few factories who holds the key technology.
In guidance of strong R&D team, we are able to produce the exceptional reliable products with the help of skillful working staff, comprehensive quality system and advanced equipments such as newest wave(flow) soldering, and burn-in testing line.
Ongoing research and being creative is what keeping our products at the top of our industry.
Our quality policy:
Everyone participates, continuous improvement, innovation.
Our management idea:
Based on good staff, concentrating on quality and efficiency, keeping on providing customers with excellent service.
Welcome to contact us today for your next OEM/ODM project.
