100A 24V Albright DC88b-317t Contactor for Electric Forklift Pallet Truck Stacker

Name: 100A 24V Albright DC88b-317t Contactor for Electric Forklift Pallet Truck Stacker
Brand: all-electronics-online.com
SKU: 823975055
Availability: InStock
Rating: 4.4 (50 reviews)

Price:	US $ 50-100/Piece
Min Order:	1/Piece
Pay Type:	T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	Albright DC88B-317T
Current:	100A

Product Description

Product Description

1. Reference

Item	Albright DC Contactor
Model	DC88B-317T
Voltage	24V
Current	100A
Size	24 x15 x15 mm
Used in	MIMA
HS code	8536411000
Net Weight	0.95 KGS

2. Product information

The DC88 motor reversing type of contactor has been designed for direct current loads, particularly motors as used on electric vehicles such as industrial trucks. The DC88 is a monoblock construction, resulting in a compact design which is compatible with modern electronic control systems. Developed for both interrupted and uninterrupted loads, the DC88 is suitable for switching Resistive, Capacitive and Inductive loads.

• Interrupted current: opening and closing on load with frequent switching (results in increased contact resistance).

• Uninterrupted current: no or infrequent load switching requirements (maintains a lower contact resistance).

The main contact circuit, designed for motor reversing, has a built in failsafe, so that if both coils are energised simultaneously the contact arrangement is open circuit. The DC88 has double breaking main contacts with silver alloy contact tips, which are weld resistant, hard wearing and have excellent conductivity. The DC88 M8 main stud terminals can be configured in a variety of ways in order to suit the application. Coil connections are by means of 6.3mm spades and mounting is via the supplied bracket and can be horizontal or vertical, when vertical the M8 contact studs should point upwards. If the requirement is for downwards orientation we can adjust the contactor to compensate for this.

3. Product Details

4. Packing&Shipping

Package:Normally we use the standard exporting packaging , we also can according to clients' request .
Shipping :
1. By Couriers: DHL, UPS, FEDEX, TNT are the main courier companies we are cooperating
2. By Air: Delivery from the Shanghai air port to customer's destination city air port.
3. By Sea: Delivery from the Shanghai sea port.

5. About Us

6. Contact person

Hefei Guang An Logistics Equipment Co., Ltd. Is located in Hefei city, which is a main production base for forklift and electrical pallet truck. Specializing in spare parts of material handling equipment, forklift and golf cart for more than 13 years. Product categories include controlling system, drive system, transmission system, hydraulic system, and product variety is more than 2000 relating to controllers, motors, contactors, connectors, sensors, battery charger etc. We are American CURTIS Agent and British ALBRIGHT Agent, and also establishing a long-time strategic cooperative relationship with the world's largest supplier of spare parts, France RELAS and Belgium TVH. We depend on high quality assuring development, and good service winning market. With strong technical developing capabilities and high-quality service, we have won the majority of customers trust and support. We are dedicated to be the leading supplier in China to offer widest range of electric pallet struck and forklift spare parts with high-level quality, competitive price and best service. We always look forward to your sincere cooperation!
