100W Constant Voltage Small Size SMPS AC DC Power Supply 15V 7A

Name: 100W Constant Voltage Small Size SMPS AC DC Power Supply 15V 7A
Brand: all-electronics-online.com
SKU: 832309475
Availability: InStock
Rating: 4.4 (129 reviews)

Price:	US $ 6.9-8.2/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	MS-100-15
Type:	Constant Voltage
Material:	Aluminum Case
Weight:	0.55kg
MOQ:	1-5PCS Sample Order
Shipping:	Sea Air DHL FedEx EMS UPS TNT
Test:	100% Full Load Burn-in Test
Voltage:	15V
Current:	7A
Output Type:	Single
Warranty:	2 Years
Output Power:	51 - 100W
Input Voltage:	110-220V
Connection Mode:	Series Switching Power Supply
Starting Mode:	Separate-excited Switching Power Supply
Voltage Regulating Mode:	Width Modulation Type
Power Supplying System:	Terminal Power Distribution Equipment
Certification:	ISO
Brand:	Weho

Product Description

100W Constant voltage small size smps ac dc power supply 15v 7a

Features:

1. AC input range selectable by switch

2. Protections: Short circuit / Overload / Over voltage / Over temperature

3. 100% full load burn-in test

4. Low cost, high reliability

5. 24 months warranty

Model		MS-100-5	MS-100-12	MS-100-15	MS-100-24	MS-100-36	MS-100-48
output	DC voltage	5V	12V	15V	24V	36V	48V
	Voltage tolerance	±2%	±1%	±1%	±1%	±1%	±1%
	Rated current	20A	8.3A	6.7A	4.2A	2.8A	2A
	Current range	0~20A	0~8.3A	0~6.7A	0~4.2A	0~2.8A	0~2A
	Rated power	100W	99.6W	100.5W	100.8W	100.8W	96W
	Ripple&noise	80mvp-p	120mvp-p	120mvp-p	150mvp-p	150mvp-p	180mvp-p
	DCvoltage ADJ.range	-9%~+10%	±10%	±10%	±10%	±10%	±10%
input	Voltage range	100~240VAC 150~373VDC
	frequency	47~63HZ
	AC current	2.4A/115VAC,1.2A/230VAC
	efficiency	79%	83%	83%	85%	85%	86%
	Inrush current	Cold start current 18A/115VAC,36A/230VAC
	Leakage current	< 3.5mA/240VAC
protection	overload	Rated output power115%~150% start over load protection
	overload	protection type:hiccup mode,auto-recovery after fault condition is removed
	Over voltage	6.8~8.2V	15.6~17.8V	18.6~20.8V	30.6~33.2V	42.6~44.2V	54.8~56.6V
	Over voltage	protection type:hiccup mode,auto-recovery after fault condition is removed
environment	Working temp,humidity	-10°C~+60°C,20%~90%RH
	Storagetemp,humidity	-20°C~+85°C,10%~95%RH non-condensing
	Withstand vibration	10~500HZ,2G 10min/1cycle,period for 60 minutes,each axes
safety	Withstand voltage	I/P-O/P:1.5KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC
safety	Isolated resistance	I/P-O/P,I/P-FG,O/P-FG:100M ohms/500VDC
Fitstandard	Safety standard	Fit UL1012
Fitstandard	EMC standard	Comply with EN55022,CLASSA
others	Dimension	1599738mm (LWH)
others	Weight/packing	0.48kg/45pcs/22.5kg
