11.1V 7800mAh 18650 3s3p Lithium Battery Pack

Name: 11.1V 7800mAh 18650 3s3p Lithium Battery Pack
Brand: all-electronics-online.com
SKU: 798615925
Availability: InStock
Rating: 4.6 (99 reviews)

Price:	US $ 12.48/Piece
Min Order:	1000/Piece
Pay Type:	L/C,T/T,D/P,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	UBT-18650-3S3P-7800-11.1V
Weight:	450g
Certicification:	Ce/RoHS
Type:	Lithium-Ion Battery Pack
Connection Mode:	Series and Parallel
Rated Capacity:	7800mAh
Usage:	LED Flashlight Torch
Electrolyte:	Lithium-Ion

Product Description

18650 11.1V 7800mAh Rechargeable Battery Pack 3S3P

18650/3S3P Li-ion Battery Pack 11.1V/7.8AH
Model:
Item	Specification		Remark
Nominal capacity	7800mAh		0.5C discharge Cell: 18650
Nominal voltage	11.1V		3.7V / 1Cell
Charging voltage	12.6V±0.05V		4.2V / 1Cell
Charging method	CC/CV		(Constant-current and -Voltage with Limited current
Standard charging time	2000mA/4hour , 3000mA/2.5hour		Battery capacity÷charging current×1.5
charging current	3000mA ( 0.4C )		0 ~ +40 °C
Maximum charging current	7800mA ( 1C )		0 ~ +40 °C
Continuous discharge current	7800mA ( 1C )		-20 ~ +60 °C
Discharge cutoff voltage	7.2V		2.4V / 1Cell
Short circuit protection	Exterior short circuit		Automatic recovery
Internal resistance	≤ 200mΩ		AC Impedance 1kHz
Cycle life	≥5 00
Operating temperature	Standard Charge	0 ~ +40 °C
	Standard Discharge	-20 ~ +60 °C
Outline dimension	L92W18H71mm		Length x wide x height
Pre-wired			Red = Positive,Black = Negative
Protection Circuit Module:PCM-Li03S8-069
Maximal continuous charging current	8A
Maximal continuous Discharging current	8A
Over-charge detection voltage	4.35V±0.025V		single cell
Over-charge release voltage	4.15V±0.05V		single cell
Over-charge detection delay time	0.5S_1.5S		single cell
Over-discharge detection voltage	2.40V±0.08V		single cell
Over-discharge release Voltage	3.0±0.10V		single cell
Over-discharge detection delay time	50_150mS		single cell
Over-current detection	20±3A		can adjust
Over-current delay time	5_15mS

Product advantage
1. High capacity, low inner resistance, long cycle life, low self-discharge .
2. Rapid charge-discharge cycle life up to more than 500 times.
3. Provide both single cells and battery packs.
4. Fast charge available.
5. Enough, stable capacity, steady discharge and high temperature discharge.
6. Customized sizes, packs, tags, labels, plugs, connectors, over current protection, temperature control protection is available
7. The batteries are applied to GPS,cordless phone, walkmans, solar lighting, electrical drills, shavers, emergency lighting and back-up power, robot etc.

Product application
(1) Portable electronic devices
(2) Bluetooth headset,
(3) Digital camera,
(4) MP3 player, MP4 player,
(5)Cellular phone, Digital phone, mobile phone,
(6) PDA,
(7) DMB,
(8) DVD, Portable DVD
(9) MID,
(10) Digital camcorder, Digital camera
(11) Electronic cigarette
(12) Notebook computer, Portable computer, Lap-top computer
(13) Electronic pen
(14) E-book,
(15) Flashlight
(16) GPS

Shipping and Payment:

1. We will ship the products within 15 workdays after receipt of payment.
2. We can ship to you by UPS/FEDEX/DHL and so on. Other shipping terms can also be arranged according to specific requirements.
3. We are not responsible for any accidents, delays or other issues that are the responsiblility of the shipping service.
4. We accept T/T, PAYPAL, Western Union, Cash and so on.

Introduction

Shenzhen Ubetter Co., Ltd, founded in 2013, has become a comprehensive battery manufacturer with the combination of R&D, manufacturing, marketing and service.

Shenzhen Ubetter, The Leader of Li-ion polymer batteries manufacturer, located in Shenzhen city, is specialized in Power battery series(such as electric-bikes, electric scooter and electric cars, etc), Storage battery, High-rate discharge Lithium ion battery(10C-60C high-rate discharge series such as air modeling and power tool etc), ). High Temperature Li-ion battery(up to 85° ), Low Temperature Polymer Li-ion battery(up to -40° ), Ultra-thin battery(up to 0.43mm). Ubetter has succeeded to solve the power battery core technologies problem: High Consistency and Excellent Safety Performance. Products' performance is leading in domestics market and in path with international standards. Products are widely employed in digital products series(such as MP3, UPS, etc. ), notebook PC series, 18650 series, and sales over 100 countries worldwide.

With over 4000 square meters dust-free workshop, 200 employees, automatic production lines and modernized equipments, Ubetter is offering reliable quality, efficient delivery and competitive price, by which we have gained global reputation. We are qualified for ISO9001, UL, CE, RoHS, IEC, UN38.3, MSDS, patent approves and National Hi-TECH Enterprise certification.

Our advantages

Shenzhen Ubetter Technology Co., Ltd. is a famous enterprise in the line of China's new energy business, mainly producing environmentally friendly power battery for electric vehicles, integrating the research and development, producing and selling of Lithium-ion Battery, wind and solar Energy Storage Battery as well as various kinds of batteries. Bearing with the spirit of pragmatism and innovation, we have been endeavoring to produce products with best quality for all walks of life by people-oriented management and high efficiency production line. Our R&D department has mustered skilled persons with over ten years' experience in battery research and developing, playing an leading role in the field of R&D of more and more series of batteries. Meanwhile we have cooperated with many big battery enterprises for many years and have numerous connections in this line of business. We have abundant battery resources with guaranteed quality. Shenzhen Ubetter Technology Co., Ltd. is located in the beautiful Dapeng bay with charming and beautiful scenery, excellent geographical location and convenient transportation.
