11 Kv Pin Type Composite Insulator

Name: 11 Kv Pin Type Composite Insulator
Brand: all-electronics-online.com
SKU: 766834955
Availability: InStock
Rating: 4.9 (146 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	FPQ-11/4T
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Rated Mechanical Bending Load (Kn):	4
Height (mm):	240
Insulation Distance (mm):	165
Min Creepage Distance (mm):	460
Application:	High-voltage
Material:	Composite Polymer
Structure:	Pin Insulator
Type:	B Type Insulator
Brand:	L&R

Product Description

Basic Info.
Origin: Yueqing, Wenzhou, Zhejiang, China
Brand Name: as customer's requirement
Model NO.:Polymer Insulator Pin Type
Material:Composite Polymer
Polymer Insulator:Pin Type
Export Markets:Global
Packaging: standard package or cilent's requirment

Product Description
This production is applied to high voltage power line service. And have features of good gydrophobicity, anti-ageing, anti-leakage trace and electric erode proof, tensile strength, strong mechanical strength, shock resistence good quakeproof and brittle failure proof, light weight easy to installation, and the installation outline of top and base are the same size with porcelain pin type, they can exchange to use each other.

type	Rated voltage (kV)	Rated mechanical bending load (kN)	Height (mm)	Insulation distance (mm)	Min creepage distance (mm)	Diameter of shed (mm)	Lightning impulse withstand voltage (kV)	P.F withstand voltage(virtual value) (kV)
FPQ-11/4T	11	4	240	165	460	142/116	105	42

Our products have being in service on electrical networks of more than more than 20 countries from 2005.

We had supplied our products and services to the below customers:

CHINESE STATE GRID,KENYA KPLC & REA,UGANDA REA & UMEME,TANZANIA TANESCO,GHANA ECG,SOUTH AFRICA ESKOM & ARB,NIGERIAL NEPA,COTE D'IVOIRE CI-ENERGIES,JORDAN EDCO & NEPCO,OMAN PDO,VIETNAM EVN,MEXICO IUSA,ECUADOR CELEC,NEPAL NEA,

......….

Here, We look forward to your joining.

Our factory had obtained ISO9001, ISO14001, OHSAS 18001, and almost of our products had been tested by CNAS certificated Laboratory, for example KEMA, Chinese National Lab, and etc
What can we do for you?

1) Good quality guarantee (2 years).

2) Competitive Price (Factory direct price).

3) Agent service in all the world.

4) On time delivery .

5) We offer sample for free.

6) Professional Technology .

7) Quality Control through the whole Manufacturing process.

a. Check the material before the production .

b. Have the random inspection during the production .

c. Make the 100% inspection before the shipment

Zhejiang Lawrence Electric Co., Ltd (referred as L&R) is located in Zhejiang China. It is composed by some branch companies, we also invested some domestic and foreign EPC projects.

L&R has possessed one of the major suppliers in the power and electrical fields for electrical

Projects in the world. Almost all products manufactured by the L&R members have been certified

By KEMA, CE, SGS and CNAS approved Lab.

L&R have been supplying Zinc Oxide Varistors, Surge Arresters, insulators, Fuse Cutouts, Air

Break switch, Load break switch, Vacuum Circuit Breaker, Isolators, Transformers, Switchgear,

Earth rods, Stay Rods, Pole Make Off, Guy grip, stay wire, Crossarm, clamp, bolts, Line hardware

And so on. Our member companies are required to have a long term proven track record of meeting contract

Obligations, superior quality, current technology and state-of-the-art manufacturing facilities.

Over a period of 10 years, our business has extended to South America, Middle East, Southeast

Asia, Africa, and other regions, and we had our sale agent and 4S maintenance company in some countries. To achieve the strategic objective of development, we are seeking for partners

For our sale agent and maintenance company in all the worldwide.
