110-240V 12W IP67 Waterproof LED Power Supply for Strip

Name: 110-240V 12W IP67 Waterproof LED Power Supply for Strip
Brand: all-electronics-online.com
SKU: 689223452
Availability: InStock
Rating: 4.9 (114 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	12W
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Housing Material:	Aluminum-Co-Metal
Usage:	Strip
Output Type:	Single
Driving Method:	LED Regulator Voltage
Circuit Structure:	PWM Controlled

Product Description

Specification:
Output Type:Single
is_customized:Yes
Input Voltage:220V
Output Current:1A
Output Voltage:220VAC
Model Number:LPV-12-12
Output Power:Other
DC output voltage/ current:12V 1A

Model		LVP-12-12	LVP-12-15	LVP-12-24
Output	DC output voltage	12V	15V	24V
	Output voltage tolerance	±1%	±1%	±1%
	Rated output current	1A	0.8A	0.5A
	Output current range	0~1A	0~0.8A	0~0.5A
	Output power	12W	12W	12W
	Ripple & noise	100mVp-p	120mVp-p	150mVp-p
	DC adjustable range	±10%	±10%	±10%
	Setup rise and hold up time	200ms,100ms,30ms.
Input	Input voltage range	170~264VAC 47~63Hz,240~370VDC
	AC input current	0.65A/230VAC
	Efficiency	78%	84%	87%
	AC inrush current	Cold start current 36A/230V
	Leakage current	<0.5mA/240VAC

Remark:1..All parameters at the unspecified condition, should be measured in the 230V input voltage ,at the rated load and 25°C.

2. Ripple and noise voltage is measured at the end of 20MHz Bandwidth of oscilloscope,12 inch Twisted pair plus 0.1u and 47u.

3. Tolerance is the sum of voltage setting error,voltage regulation rate and current regulation rate.
