12/24 Core MPO Om3/Om4 Trunk Cable Fiber Optic Patch Cord

Name: 12/24 Core MPO Om3/Om4 Trunk Cable Fiber Optic Patch Cord
Brand: all-electronics-online.com
SKU: 804048325
Availability: InStock
Rating: 4.7 (49 reviews)

Price:	US $ 1.2/Piece
Min Order:	100/Piece
Pay Type:	L/C,T/T,Western Union,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	TK-H0004
MOQ:	100PCS
Color:	Aqua/Yellow or Customized
Insertion Loss:	<0.3dB
Warranty:	5 Years
Cable Diameter:	0.9mm/2.0mm/3.0mm
Delivery Time:	5 Days
Sample:	Available
Return Loss:	>60dB
Fiber Connector:	MPO or MTP for Optional
Item Name:	12/24 Core MPO Om3/Om4 Trunk Cable Fiber Optic Pat
Application:	Communication
Type:	Multi-mode Fiber
Certification:	CE
Connection Structure:	MPO/MTP
Core:	Single or Multi Core

Product Description

12/24 Fiber MPO OM3 Trunk Cable Patch Cord

CABLE Quality Assurance System:
* Test Specifications for Bellcore GR-409-core
* Smoke density Purpose IEC-61034
* Halogen Acid Content IEC-754-1
* Flame Resistance IEC 60332-1, IEC 60332-3
* Conform to WEEE RoHS standard.

Feature:
1).Low insertion loss
2).High return loss (low amounts of reflection at the interface)
3).Ease of installation
4).Low cost
5).Reliability
6).Low environmental sensitivity
7).Ease of use

Application:
1).CATV
2).Active device termination
3).Telecommunication networks
4).Metro
5).Local Area Networks (LANs)
6).Data processing networks
7).Test equipment
8).Premise installation
9).Wide Area Networks(WANs)

Fiber Optic Performance:

Item		Parameter
MPO/MTP Connector		Standard SM	Low Loss(Elite) SM	Standard MM	Low Loss MM
Insertion Loss	Typical	0.35dB	0.20dB	0.35dB	0.20dB
	Maximum	0.75dB	0.35dB	0.60dB	0.35dB
Return Loss		≥60 for APC (8 Angle Polish)		≥20 for PC
		≥50 for PC		--
Male/Female		Male: With Pins, Female: Without Pins
Tensile Strength		≤0.3 (Max 66N)
Vibration		≤0.3 (10 ~ 55Hz)
Thermal Cycle		≤0.3 (-40 ~ 75ºC, 21Cycles)

Thanks for reference our products.

Should you have any question please feel free to contact me.

Certification approval:

Takfly Worldwide Exhibition

Thank you for refer our products, should you have any question please feel free to contact me.

Takfly Communications Co., Ltd. is a Hi-Tech enterprise having its own brand and specializing in R&D, manufacture and sales of fiber optical communications equipments.

The main products of TAKFLY include fiber optic patch cord, connector, adapter, optical coupler, attenuator, optic media converter, optic splice closure, optic terminal box, ODF etc, which are widely used in telecommunications, broadband, broadcast, CATV and network industry. All the products acquired the approval of the Network Access License for Telecommunication Equipment Ministry of Information Industry, PRC, ISO9001, UL and CE standard, which ensure the reliability and make them sold very well not only in the domestic market but also the overseas market.

TAKFLY was establish in 2000, grow up rapidly. Now it has workshop area about 3000 square meters, more than 200 workers, the production capacity of fiber optic connectors is about 600, 000PCS per month. It controls the quality constantly and strictly in order to give the best products to the users. The outstanding features and advantage are the high technology, professional and excellent sales team, efficient and sound management, competitive price, wide and superior channels, as well as high-quality and flexible service.

Many international exhibitions upgraded "TAKFLY" as the well-known brand in the world. To be the super leader of the optical communications scopes in China is the goal of TAKFLY. In the next five years, TAKFLY will keep the strategic pattern of development ---"based in South China, penetrate into whole country, extend over the world". It will bring the fiber optic industry into a brilliant future. TAKFLY--- Your Honest Team, will be always ready for you.
