| Prod Model: |
12V100AH (6FM100G) |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Color: |
Grey or Black |
| Terminal: |
F11 |
| Usage: |
Car, Electric Power, Lighting, Boat, Bus, Electric Bicycle, UPS |
| Nominal Voltage: |
12V |
| Discharge Rate: |
Low Discharge Rate |
| Shape: |
Square Battery |
| Electrolyte: |
Acid |
| Installation: |
Fixed |
| Rechargeable: |
Chargeable |
| Type: |
Lead-Acid Batteries |
Product Description
12 volt Lead acid battery deep cycle battery wheelchair battery 12V100ah
Longway Deep Cycle series batteries(DC Type, "DC"behind the model name stands for deep-cycle application)are designed to have a large amount of stored current discharged between charging sessions, with very heavy non-porous battery plates to withstand repeated major
Discharging and charging cycle(deep cycle).
Longway Deep-cycle battery uses a different chemistry for the plates active paste material, and a slightly stronger electrolyte than normal battery electrolyte, which allows for a much longer life in deep cycle applications.
Trademark: Long way
Model: 6FM100DC(12V100Ah/10hr)
Size: 327*170*216 (total height 223 ) mm
More size available
Terminal: B
10hr: 105Ah
Packing qty: 1 PCS/CTN
750 PCS/container
Lead-time: 15 days for one container
Application: UPS, inverter, solar system
OEM acceptable
Standard: JIS IEC
Productivity: 40, 000 PCS
Unit price/payment: FOB CIF CNF/tt or L/C at sight
Packing: 1PCS/CTN
Min. Order: 60 PCS
Transportation: By sea
Applications
Ø Alarm systems, Cable television, communications equipment, control equipment,
Ø Computers, electronic cash registers, electric test equipment,
Ø Electric powered bicycle and wheel chair,
Ø Emergency lighting systems, fire&security, geophysical equipment,
Ø Marine equipment, medical equipment,
Ø Micro processor based office machines, portable cine&video lights,
Ø Power tools, solar powered systems,
Ø Telecommunications systems, television&video recorders, toys,
Ø Uninterruptible power supplies, vending machines;
General Features
12 years design life at floating conditions.
Long life ecpectancy of 5 years at renewable energy system.
Wide temperature range from -20 to 60 degress Celsius.
Nano gel electrolyte eliminate the acid stratification and prolong cycle life.
Round trip efficiency as high Tin low Ca alloy and high density paste.
Low self-discharge rate and long shelf life (1 year at 25 degress Celsius).
Excellent deep discharge recovery capability.
Our factory photo
Our certificate
If any interest, welcome to contact us freely.| Standby Deep Cycle series batteries |
| Battery Model | Nominal Voltage(V) | Nominal Capacity
(AH) | Length | Width | Height | Total Height | Weight(5%) | Terminal |
| In | mm | In | mm | In | mm | In | mm | Pound | Kg | Type | Position |
| 3FM100DC | 6 | 100 | 7.68 | 195 | 6.69 | 170 | 8.15 | 207 | 8.35 | 212 | 36.4 | 16.5 | F10 | A |
| 3FM150DC | 6 | 150 | 10.2 | 260 | 7.09 | 180 | 9.72 | 247 | 9.92 | 252 | 51.8 | 23.5 | F10 | B |
| 3FM200DC | 6 | 200 | 12.7 | 323 | 7.01 | 178 | 8.82 | 224 | 9.02 | 229 | 63.9 | 29.0 | F10 | A |
| 3FM225DC | 6 | 225 | 9.6 | 243 | 7.38 | 187.5 | 10.83 | 275 | 10.83 | 275 | 70.5 | 32.0 | F12 | B |
| 6FM12DC | 12 | 12 | 5.94 | 151 | 3.86 | 98 | 3.74 | 95 | 3.98 | 101 | 8.27 | 3.75 | F2 | F |
| 6FM18DC | 12 | 18 | 7.13 | 181 | 3.03 | 77 | 6.57 | 167 | 6.57 | 167 | 11.9 | 5.40 | F4 | D |
| 6FM24DC | 12 | 24 | 6.89 | 175 | 6.54 | 166 | 4.96 | 126 | 4.96 | 126 | 16.8 | 7.60 | F4/F8 | D |
| 6FM28DC | 12 | 28 | 6.5 | 165 | 4.96 | 126 | 6.89 | 175 | 7.01 | 178 | 18.7 | 8.50 | F14/F9 | D |
| 6FM33DC | 12 | 33 | 7.68 | 195 | 5.12 | 130 | 6.34 | 161 | 6.54 | 166 | 23.1 | 10.5 | F9 | C |
| 6FM40DC | 12 | 40 | 7.8 | 198 | 6.54 | 166 | 6.69 | 170 | 6.69 | 170 | 28.7 | 13.0 | F9 | D |
| 6FM55DC | 12 | 55 | 9.02 | 229 | 5.43 | 138 | 8.19 | 208 | 8.39 | 213 | 38.6 | 17.5 | F9/F20 | C |
| 6FM60DC | 12 | 60 | 10.2 | 259 | 6.65 | 169 | 8.19 | 208 | 7.17 | 213 | 43.0 | 19.5 | F9 | C |
| 6FM65DC | 12 | 65 | 13.78 | 350 | 6.50 | 165 | 7.17 | 182 | 8.62 | 182 | 46.3 | 21.0 | F6/F9 | C |
| 6FM75DC | 12 | 75 | 10.2 | 260 | 6.61 | 168 | 8.43 | 214 | 8.46 | 219 | 51.8 | 23.5 | F9 | C |
| 6FM80DC | 12 | 80 | 12.09 | 307 | 6.57 | 167 | 8.27 | 210 | 8.46 | 215 | 55.1 | 25.0 | F9 | C |
| 6FM90DC | 12 | 90 | 12.09 | 307 | 6.57 | 167 | 8.27 | 210 | 8.46 | 215 | 62.8 | 28.5 | F9 | C |
| 6FM100DC | 12 | 100 | 13 | 330 | 6.81 | 173 | 8.62 | 219 | 8.82 | 224 | 66.1 | 30.0 | F11 | C |
| 6FM120DC | 12 | 120 | 16 | 406 | 6.77 | 172 | 9.29 | 236 | 9.29 | 236 | 77.2 | 35.0 | F11 | C |
| 6FM150DC | 12 | 150 | 19 | 483 | 6.69 | 170 | 9.49 | 241 | 9.49 | 241 | 98.1 | 44.5 | F11/F18 | C |
| 6FM160DC | 12 | 160 | 13.4 | 341 | 6.81 | 173 | 11.14 | 283 | 11.34 | 288 | 99.2 | 45.0 | F10 | C |
| 6FM180DC | 12 | 180 | 20.6 | 522 | 9.45 | 240 | 8.62 | 219 | 8.82 | 224 | 125.7 | 57.0 | F12/F19 | E |
| 6FM200DC | 12 | 200 | 20.6 | 522 | 9.45 | 240 | 8.62 | 219 | 8.82 | 224 | 132.3 | 60.0 | F12/F19 | E |
| 6FM250DC | 12 | 250 | 20.5 | 520 | 10.59 | 269 | 8.66 | 220 | 9.65 | 245 | 163.1 | 74.0 | F12/F19 | E |
Kaiying Power Supply & Electrical Equip Co., Ltd., established in 2001, is a professional valve regulated sealed lead acid battery manufacturer in China. We have a lot of experience in producing high quality products. There is a group of engineers to develop batteries as our clients required.
As the environmental readjusted, Zhangshan Long Way Battery Manufacturing Co., Ltd couldn't produce SLA batteries anymore. The technology and IQC management of Zhangshan Long Way Battery Manufacturing Co., Ltd which had merged with KAIYING GROUP, the Logo LONGWAY is also transferred to the KAIYING GROUP.
Kaiying Power Supply & Electrical Equip Co., Ltd., with a 10, 000 M² Factory space, the company has over 1000 employees and advanced development equipment and comprehensive test facilities. Attaching great importance to quality, our management comply with ISO9001-2000 standard. Our batteries have UL and CE approvals.
During the past several years, the company has gained a very high reputation in the industry with excellent development, production, sales capability and premium quality. So, we got very good market share both in the domestic and foreign markets in the past. OEM orders acceptable.
