Deson Electric Group Company Limited >> 12000va Wall Mounted Full Automatic AC Voltage Stabilizer Srw-12000-D

12000va Wall Mounted Full Automatic AC Voltage Stabilizer Srw-12000-D

12000va Wall Mounted Full Automatic AC Voltage Stabilizer Srw-12000-D
Price: US $ 1/Piece
Min Order: 1/Piece
Pay Type: L/C,T/T,Western Union,Paypal,Money Gram
Prod Model: SRW-12000-D
Input Voltage: AC140-260V
Output: 220V+-8%
Power: 12000va
Current Type: AC
Phase: Single Phase
Usage: SVC
Frequency: Low Frequency
Brand: Deson

Product Description

Introduction:

SRW Series wall mounted LED relay type full automatic AC voltage regulator adopts the international advanced technology and intelligent CPU centralized control technology. It has the advantages of high efficiency, beautiful appearance and reliable performance etc. All products have over voltage, delay, temperature and error production and also voltage two-way indication. All indicator gauges are digital display, it leaves you a brand-new impression. These high performance products are specialized for users of unstable voltage and precision electronic instruments and equipment.



Advantage:



•Suitable for wall mounting

•Microprocessor control

•Number of relays 3 +1
•The high output voltage accuracy (220V ± 8%)
•Current protection
•Differentiation and fault indication
•Informative LED-display
•Modern design
•urge protection up to 300 V
•High speed regulation
•The wide input voltage range
•The multistage defense



Product Parameter :



Model

SRW-500-M

SRW-1000-M

SRW-1500-M

SRW-2000-M

SRW-3000-M

SRW-5000-D

SRW-10000-D

SRW-12000-D

Power capacity

350W

700W

1050W

1400W

2100W

3500W

7000W

8400W

Input voltage

AC 140-260V

Output voltage

220V±8%

Phase

Single Phase

Frequency

50-60Hz

Adjust time

1 second

Type of stabilization

Relay

Display

LED digital display

Protection over voltage

250±2V

Protection lack voltage

185±2V

Mode Bypass

No

Efficiency

98%

Type of connection

Terminal block

Degree of protection

IP20

Delay

5 second

Temperature protection

110°C±10°C

Ambient Temperature

-10~+45°C

Relative humidity

80%

Waveform distortion

No additional wave form distortion

Dimension of device

(L*W*H)(mm)

120*85*70

120*85*70

120*85*70

120*85*70

220*170*210

220*170*210

220*170*210

536*394*270

Weight of device

3Kg

3Kg

4.5Kg

5.5Kg

12.5Kg

13.5Kg

16Kg

19.7Kg








Our company supplies different kinds of products. High quality and favorable price. We're pleased to get your Inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective. To perfect our service, we provide the products with good quality at the reasonable price.
