120W 90mm Single / Three Phase Electric AC Induction Motor

Name: 120W 90mm Single / Three Phase Electric AC Induction Motor
Brand: all-electronics-online.com
SKU: 743461275
Availability: InStock
Rating: 4.3 (23 reviews)

Price:	US $ 32-38/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	T/T,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	5IK120GU-AF (5IK120A-AF)
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Power:	10/15/20/25/40/60/90/120/140/180W
Size:	60/70/80/90/100mm
All Technical Data:	Can Be Customized
Function:	Driving
Brand:	GS
Number Of Stator:	Single / Three Phase
Certification:	CE

Product Description

120W 90mm ac induction motor

Specifications
1. Dimensions of device: 90mm
2. Rated Power: 120W
3. Voltage: 110V / 120V / 220V / 230V
4. Rated Speed: 1250RPM / 1550 RPM
5. Rated Torque: 750mN. M / 930 mN. M

FOR OTHER MODEL:

Size: 60 / 70 / 80 / 90 / 100mm
Power: 10 / 15 / 20 / 25 / 40 / 60 / 90 / 120 / 140 / 180W
Voltage: 1ph100 / 1ph110 / 1ph120 / 1ph220 / 1ph230 / 3ph220 (50/60Hz)
Gear Ratio: 3/ 3.6/ 5/ 6/ 7.5/ 9/ 12.5/ 15/ 18/ 25/ 30/ 36/ 50/ 60/ 75/ 90/ 100/ 120/ 140/ 180/ 200

Note: Motor voltage, power and speed will be customized according to your request under the allowed circumstance of adoptable dimension.

If you have any other questions, please feel free to contact us.

Model		Output power W	Voltage V	Frequency Hz	Current A	Starting Torque mN.m	Rated Torque mN.m	Rated Speed r/min	Capacitor μF
Lead Wire Type	Terminal Box Type
5IK120GU-AF (5IK120A-AF)	5IK120GU-AFT (5IK120A-AFT)	120	1ph100	50	2.10	600	930	1250	30.0
				60	2.50		750	1550
5IK120GU-EF (5IK120A-EF)	5IK120GU-EFT (5IK120A-EFT)	120	1ph110	60	1.65	600	750	1550	25.0
			1ph120		1.80
5IK120GU-CF (5IK120A-CF)	5IK120GU-CFT (5IK120A-CFT)	120	1ph220	50	1.00	650	930	1250	7.0
			1ph230		0.95
5IK120GU-HF (5IK120A-HF)	5IK120GU-HFT (5IK120A-HFT)	120	1ph220	60	1.00	600	750	1550
			1ph230		0.95
5IK120GU-SF (5IK120A-SF)	5IK120GU-SFT (5IK120A-SFT)	120	3ph220	50	0.70	1850	930	1250	_
				60	0.60	1600	750	1550
