120W Single Output SMPS DIN Rail Switch Mode Power Supply

Prod Model:	DR-120
Power:	120W
Input:	85 ~ 264VAC 120 ~ 370VDC
Output:	5V/12V/24V
Size:	55X125X100mm
Weight:	0.55kgs
Output Type:	Single
Warranty:	2 Years
Input Voltage:	Full Range
Connection Mode:	Series Switching Power Supply
Starting Mode:	Self-excited Switching Power Supply
Voltage Regulating Mode:	Frequency Modulation Type
Power Supplying System:	Terminal Power Distribution Equipment
Certification:	CCC
Output Power:	120W
Brand:	Deson
Energy Transmission:	Switch Mode Power Supply

Product Description

120W Single Output SMPS Din Rail Switch Mode Power Supply

1.Universal AC Input / Full Range
2.Installed on DIN rail TS35/ 7.5 or 15
3.Protection : short circuit/Overload/Over voltage/ Over temperature
4.Cooling by free air convection
5.100% full load burn-in test
6.Din Rail Installation
7.Isolation Class 2
8. 2 years warranty


Product Description


Model	DR-120-12	DR-120-15	DR-120-24	DR-120-48
DC output voltage	12V	15V	24V	48V
Output voltage range	±2%	±2%	±1%	±1%
Rated output current	10A	8A	5A	2.5A
Output current range	0-10A	0-8A	0-5A	0-2.5A
Wave and noise	85mVp-p	85mVp-p	85mVp-p	100mVp-p
Inlet stability	±0.5%	±0.5%	±0.5%	±0.5%
Load stability	±1%	±1%	±1%	±1%
DC output power	120W	120W	120W	120W
Efficiency	80%	81%	84%	85%
Adjustable range for DC voltage	10.8~13.2V	13.5~16.5V	21.6~26.4V%	43.2~52.8V%
AC input voltage range	88~132VAC 47~63Hz;240~370VDC
Input current	3.3A/115V 2A/230V
AC inrush current	Cold-start current 30A/115V 60A/230V
Leakage current	<3.5mA/240VAC
Overload protection	105%~150% Type: pulsing hiccup shutdown Reset: tuto recovery
Over-voltage protection	13.8~16.2V	18~21V	27.6~32.4V	58~62V
Temperature coefficient	±0.03%/°c(0~50°c)
Setup, rise , hold up time	500ms,70ms, 50ms/230V
Vibration	10~500Hz, 2G 10min,/1cycle, Period for 60min, Each axes
Withstand voltage	Input and output internal: Input and encolsur: 1.5KvAC, Output and enclosure: 0.5KvAC
Isolation resistance	Input and output internal: Input and enclosure, Output and enclosure:500VDC/100MΩ
Working temperature and humidity	10°c~50°c(Refer to output derating curve), 20%~90%RH
Overall dimension	65.5×125.2×100mm
Weight	0.8Kgs 24PCS/19.2Kg/1.1CUFT
Safety standards	Meet UL 1012 requiement (Not apply for the mark)
EMC standards	Meet FCC PART 15 J Conduction class B
