12AWG Single Core Thhn Thwn Wire

12AWG Single Core Thhn Thwn Wire
Price: US $ 0.1-0.49meter
Trade Terms: FOB,CFR,CIF
Min Order: 1meter
Pay Type: L/C,T/T,D/P,Western Union,Paypal
Prod Model: THHN / THWN
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Jacket: Nylon
Rate Voltage: 600V
Nominal Sectional Area: From AWG #6 to AWG #18
Experience: 20 Years
Type: Insulated
Conductor Type: Stranded
Insulation Material: PVC
Certification: CCC
Application: Indoor
Conductor Material: Copper or Copper Clad Aluminum
Material Shape: Round or Flat
Brand: Jinshui

Product Description

THHN THWN WIRE



Application and Constructure:

1: THHN: It indicates a single or stranded conductor having flame-retardant and heat-resistant thermoplastic insulation with a jacket of extruded nylon or equivalent material. The wire is rated 90oC dry only.

2: THWN: It indicates a single or stranded conductor having flame-retardant, moisture and heat resistant thermoplastic insulation with a jacket of extruded nylon or equivalent material. The wire is rated 75oC wet or dry

3: Conductor: Annealed solid or stranded copper wires

4: Insulation: Polyvinyl Chloride (PVC) Rated 105oC

5: Jacket: Nylon jacket is provided to protect PVC insulation against abrasions and scratches while pulling through conduits. It is also resistant to oil, gasoline and chemicals.



PACKAGING:
A: Roll of 100 m.
B: Reel of 1500 m.
C: Reel of 1000 m.
D: Reel of 500 m.
E: Multiple Reels of 1000 m.
Z - Length to the client's requirement.




AVAILABLE COLORS:
Cables (Size 20 to 10 AWG): Black, White, Sky Blue, Blue, Red, Purple, Yellow and Green.
Cables (Size 8 to 2 AWG): Black, White, Blue and Red.
Cables (Size 1 to 1000 MCM): Black.
Part NumberAWG SizeConductor StrandingNom. O.D. (in)Nom. Insul. Thick. (in)Jacket ThickApprox LBS/MFTAmpacity @ 90°C
THHN 14 114Solid0.1020.0150.0041515
THHN 14 191419/270.1090.0150.0041615
THHN 12 112Solid0.1190.0150.0042320
THHN 12 191219/250.1280.0150.0042420
THHN 10 110Solid0.1610.0200.0043830
THHN 10 191019/230.1610.0200.0043830
THHN 8 19819/210.2130.0300.0056355
THHN 6 19619/.03720.2490.0300.0059575
THHN 4 19419/.04690.3180.0400.00615295
THHN 3 19319/.05260.3460.0400.006189110
THHN 2 19219/.05910.378 ,0.0400.006234130
THHN 1 19119/.06640.4350.0500.007299150
THHN 1/0 191/019/.07450.4740.0500.007372170
THHN 2/0 192/019/.08370.5180.0500.007462195
THHN 3/0 193/019/.09400.5680.0500.007575225
THHN 4/0 194/019/.10550.6240.0500.007718260
THHN 250 3725037/.08220.6780.0600.008851290
THHN 300 3730037/.08220.7300.0600.0081012320
THHN 350 3735037/.09730.7770.0600.0081174350
THHN 400 37400370.8210.0600.0081334380
THHN 500 37500370.9020.0600.0081655430
THHN 600 61600610.9980.0700.0091987475
THHN 750 61750611.1260.0700.0092464535
THHN 1000 611000611.2750.0700.0091275615

======================================================
