12kv High Voltage Polymer Composite Post Insulator (FZS-40.5/6)

Name: 12kv High Voltage Polymer Composite Post Insulator (FZS-40.5/6)
Brand: all-electronics-online.com
SKU: 618785662
Availability: InStock
Rating: 4.3 (95 reviews)

Price:	US $ 3.88/Piece
Trade Terms:	FOB,others
Min Order:	10/Piece
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	FZS-40.5/6
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Chemistry:	Hybrid Insulation
Thermal Rating:	250 250
Rated Voltage:	12kv
Creepage Distance:	300mm
Application:	Low-voltage
Material:	Composite Polymer
Structure:	Post Insulator
Type:	Solid
Size Of Bearing Capacity:	5kn
Brand:	Powlik

Product Description

12KV High Voltage Polymer Composite Post Insulator (FZS-40.5/6)

1.Description
Composite post insulator, applicable to substation, has good characteristics of water hydrophobe, aging resistance, tracking resistance, and corrosive resistance. They have high electrical performance: Silicone rubber sheds are good in hydrophobe and have water floating capacity, heavy pollution resistance, can prevent flash over due to pollution. It can work on the severely polluted sites without special clearing. The top and bottom installation sizes can be designed same to those of porcelain post insulators.

2.Main technical data
Type: Fzs-12/2.5
Rated voltage: 12kv
Height: 215mm
Min. Arcing distance: 129mm
Min. Creepage distance: 300mm
Mechanical failing load/bending load: 5kn
Distortion load: 0.6kn
Power frequency withstand voltage wet: 30kv
Dry: 42kv
Full wave lighting impulse withstand voltage: 75kv

Minyang Group Co., Ltd. Mainly specilized in manufacturing and supply busbar trunking system, power transformer, insulator, fuse cutout, voltage stabilizer, surge arrester, power supply, Load breaker switch, isolating switch, switchgear sets, substations, cables and wires etc.

MINYANG GROUP located in Liushi, the electric capital of China, is specialized in developing, manufacturing and distributing power supplies & switchgears, along with about 150 components.

MINYANG GROUP established with 5 specilized manufacturing factories, Owning skilled workers, advanced equipment and strict quality control process, MINYANG has passed ISO9001: 2000 and obtained CE, CB, CCC etc. Certificates. Our products are enjoying high popularity in Bangladesh, India, UAE, Iran, Saudi, South Africa and Brazil etc.

MINYANG takes "quality is life of enterprise"as its tenet, rewards customers with quality products and perfect services, and creates brilliant future in Chinese electric equipment industry.
