0.12kw/ 4poles Ms Series Aluminum Housing Three-Phase Induction AC Asynchronous Motors

Prod Model:	MS631-4
Number Of Stator:	Three-Phase
Function:	Driving
Brand:	Xr
Certification:	Ce

Product Description

1.MS Series Three-Phase Asynchronous Motors Aluminum Housing

Motor Basic Information
Frame size	56-180
Pole	2/4/6/8
Rated voltage	220/380V;380/660;230/400;400/690
Frequency	50/60Hz
Power	0.06kw-22Kw
Protection degree	IP54/55
Implement Method	B3/B14/B34/B5/B35
Cooling method	IC411
Insulation class	F
Ambient Temperature	-15°C~40°C
Altitude	not exceed 1000 Meter
Working Duty	S1(Continuous)

MS  series aluminium housing three phase asynchronous motors, with latest design  in entirety, are made of selected quality materials and conform to the IEC standard.

MS motors have good performance, safety and reliable operation, nice appearance, and can be maintained very conveniently. Also with low noises, little vibration and at the same time light wieght and simple construction, these motors can be used for general drive.


2.PERFORMANCE DATA

Model	output		Voltage	Speed	Current	Eff.	Power factor	Tstar/Tn	Tmax/Tn	Start current
	KW	HP	(V)	(r.p.m)	(A)	(%)	(cosΦ)
				2 Poles/3000rpm/50HZ
MS561-2	0.09	0.12	220/380	2800	0.57/0.33	62	0.68	2.3	2.4	6
MS562-2	0.12	0.16	220/380	2800	0.67/0.38	67	0.71	2.3	2.4	6
MS631-2	0.18	0.25	220/380	2800	0.91/0.53	69	0.75	2.2	2.4	6
MS632-2	0.25	0.34	220/380	2800	1.17/0.68	72	0.78	2.2	2.4	6
MS711-2	0.37	0.5	220/380	2800	1.65/0.95	73.5	0.8	2.2	2.4	6
MS712-2	0.55	0.75	220/380	2800	2.33/1.35	75.5	0.82	2.2	2.4	6
MS801-2	0.75	1	220/380	2800	3.03/1.75	76.5	0.85	2.2	2.4	6
MS802-2	1.1	1.5	220/380	2800	4.42/2.55	77	0.85	2.2	2.4	6
MS90S-2	1.5	2	220/380	2800	6.01/3.84	77	0.85	2.2	2.4	6
MS90L-2	2.2	3	220/380	2800	8.61/4.98	78	0.86	2.2	2.4	6
MS100L-2	3	4	220/380	2800	11.1/6.4	82	0.87	2.2	2.3	7
MS112M-2	4	5.5	380/660	2800	8.2/4.7	85.5	0.87	2.2	2.3	7
MS132S1-2	5.5	7.5	380/660	2800	11/6.3	85.5	0.88	2	2.2	7
MS132S2-2	7.5	10	380/660	2800	15/8.6	86.2	0.88	2	2.2	7
MS160M1-2	11	15	380/660	2800	21.3/12.2	88	0.88	2	2.2	7
MS160M2-2	15	20	380/660	2800	28.7/16.4	89	0.89	2	2.2	7
MS160L-2	18.5	25	380/660	2800	34.6/19.8	90	0.9	2	2.2	7
MS180M-2	22	30	380/660	2800	40.9/23.4	90.5	0.9	2	2.2	7
				4 Poles/1500rpm/50HZ
MS561-4	0.06	0.08	220/380	1400	0.49/0.28	56	0.58	2.3	2.4	6
MS562-4	0.9	0.12	220/380	1400	0.67/0.39	58	0.61	2.3	2.4	6
MS631-4	0.12	0.16	220/380	1400	0.84/0.48	60	0.63	2.2	2.4	6
MS632-4	0.18	0.25	220/380	1400	1.12/0.65	64	0.66	2.2	2.4	6
MS711-4	0.25	0.34	220/380	1400	1.44/0.83	67	0.68	2.2	2.4	6
MS712-4	0.37	0.5	220/380	1400	1.94/1.12	69.5	0.72	2.2	2.4	6
MS801-4	0.55	0.75	220/380	1400	2.69/1.56	73.5	0.73	2.2	2.4	6
MS802-4	0.75	1	220/380	1400	3.48/2.01	75.5	0.75	2.2	2.4	6
MS90S-4	1.1	1.5	220/380	1400	4.74/2.75	78	0.78	2.2	2.4	6
MS90L-4	1.5	2	220/380	1400	6.31/3.65	79	0.79	2.2	2.4	6
MS100L1-4	2.2	3	220/380	1430	8.6/5	81	0.82	2.2	2.3	7
MS100L2-4	3	4	220/380	1430	11.7/6.8	82.5	0.81	2.2	2.3	7
MS112M-4	4	5.5	380/660	1430	8.8/5.1	84.5	0.82	2.2	2.3	7
MS132S-4	5.5	7.5	380/660	1440	12/6.9	85.5	0.84	2.2	2.2	7
MS132M-4	7.5	10	380/660	1440	15/8.6	87	0.85	2.2	2.2	7
MS160M-4	11	15	380/660	1460	22.3/12.7	88	0.85	2	2.2	7
MS160L-4	15	20	380/660	1460	30.17.1	89	0.85	2	2.2	7
MS180M-4	18.5	25	380/660	1470	36.4/20.8	90.5	0.85	2.2	2.2	7.5
MS180L-4	22	30	380/660	1470	43.1/24.6	91	0.85	2.2	2.2	7.5
				6 Poles/1000rpm/50HZ
MS90S-6	0.75	1	220/380	910	4.0/4.3	72.5	0.7	2.2	2.2	5.5
MS90L-6	1.1	1.5	220/380	910	5.5/3.2	73.5	0.72	2.2	2.2	5.5
MS100L-6	1.5	2	220/380	940	6.9/4.0	77.5	0.74	2.2	2.2	6.5
MS112M-6	2.2	3	220/380	940	9.7/5.6	80.5	0.74	2.2	2.2	6.5
MS132S-6	3	4	220/380	960	12.4/7.2	83	0.76	2	2	6.5
MS132M1-6	4	5.5	380/660	960	9.4/5.4	84.5	0.77	2	2	6.5
MS132M2-6	5.5	7.5	380/660	960	13/7.5	85.3	0.78	2	2	6.5
MS160M-6	7.5	10	380/660	970	16.5/9.43	86.2	0.8	2	2	6.5
MS160L-6	11	15	380/660	970	24.1/13.8	87.5	0.79	2	2	6.5
MS180L-6	15	20	380/660	970	31.5/18	89	0.81	2	2	7
				8 Poles/750rpm/50HZ
MS132S-8	2.2	3	220/380	710	10/5.8	85.5	0.71	2	2	5.5
MS132M-8	3	4	220/380	710	13.3/7.7	82	0.72	2	2	5.5
MS160M1-8	4	5.5	380/660	720	10.2/5.8	81	0.73	2	2	6
MS160M2-8	5.5	7.5	380/660	720	13.6/7.8	83	0.74	2	2	6
MS160L-8	7.5	10	380/660	720	17.7/10.1	85.5	0.75	2	2	6
MS180L-8	11	15	380/660	730	25.1/14.3	87.5	0.76	2	2	6.5

3.FAQ
Q: What is your MOQ of this item?
A: Generally, 1*20GP.
     For the first time cooperation, we accept trial sample order.

Q: What's your payment terms?
A: 30% T/T deposit, 70% balance before shipment or L/C at sight.

Q: What's the delivery time?
A: 30 days after receiving your L/C or T/T deposit.

Q: Can we used our own brand on motors ?
A: Sure, we can offer OEM service,
     manufacture with your authorized brand.

4.XR has it advantage in comprehensively intergrat all the strenghts belowing to make good quality products:
*automatic&semi-automatic progressive punching machine: we can punch lamination all by ourselves;

*automatic stator embedding wire and shaping: we have perform automatic embedding and shaping;

*advanced powder coating technique: which has stronger adhesiveness than painting.It makes motor appearance even, fine&smooth,also stand up to peeling off;

*Three labs:Frame 56-355 motor are available for type testing operation, which provides a matured technology support   platform for high-quality electric motor.


5.Our Service:
*You inquiry related to our products or price will be replied no more than 24 Hours;

*Well-trained& experienced staff to answer your enquiries in fluent English;

*OEM& ODM, XR can help to design and produce motors according to your customized requirement;

*Protection of your sales area, ideas of design& all your private information.

Any questions or enquiry are well welcomed by tel:0593-6937775.
