| Prod Model: |
SNG-12100 |
| Name: |
Deep Cycle Free Mainteance Gel Battery |
| Company: |
Manufacturer&Package |
| OEM/ODM Service: |
Acceptable |
| Voltage: |
12V |
| Battery Capacity: |
100ah |
| MOQ: |
1 Piece |
| Warranty: |
3 Years |
| Life Span: |
5 Years |
| Country Of Origin: |
Guangdong,China |
| Color: |
White |
| Type: |
Lead-Acid Batteries |
| Usage: |
Electric Bicycle |
| Nominal Voltage: |
12V |
| Discharge Rate: |
Low Discharge Rate |
| Shape: |
Square Battery |
| Rechargeable: |
Chargeable |
| Electrolyte: |
Gel Battery |
Product Description
12V 100AH Deep Cycle Free Mainteance Gel Battery for Solar Power System
Products description:Solar polymer gel battery can be used for solar systems, wind power generation systems, uninterruptible power supply (UPS), inverter, EPS, street lamps and other products supporting the use
Features:*Charge and discharge accept ability:
By using automatic safety valve, can prevent abnormal internal pressure caused by charging generate gas from damaging the battery. Full sealed battery under normal floating would be no electrolyte and acid fog. At the same time, the independent patent technology of battery tray with battery, ensure the battery be used more secure
*Long service lifetime:
Computer design the corrosion resistance of calcium, lead tin alloy plate gate, ABS corrosion resistant material shell, high seal reaction efficiency, so as to ensure the long service life of the battery.
*Low self-discharge rate:
Used special lead calcium alloy, strictly control the separator, electrolyte, and other working procedure impurities, under the environment 20 ºC, battery don't need adding electricity energy in 6 months and can be normal used.
*Strength conductive capability:
Use copper silver plated terminals and special design, guarantee the excellent electrical properties
Strength ability to environment:
Can be used in -25 ºC ~+ 50 ºC ambient temperature, suitable for bad weather.
*Strength direction:
High efficiency to sealed reaction. Either standing or lying, battery will not leak to ensure normal use
*Green and pollution-free
Mute and no pollutant discharge. Battery room doesn't need acid anticorrosion measures, it can be built in one room with electronic equipment and other equipment
*New active polymer gel battery series have longer service life and deep cycle features:
*Adopt special slicker solder multivariate anode alloy, corrosion resistance stronger than traditional lead calcium alloy, cycle life is more superior. Optimize the grid distribution design, has the stronger output power
*Unique lead paste formula and manufacturing process, adequately conducive to the formation of 4 bs , make sure the battery has a longer floating service life.
*The rational use of additives,. Make the PCL (capacity early losses) to be better solution
Technical Parameter| Model | SNB-100 |
| External dimensions | 329*172*214cm |
| Net weight | 31kg |
| Packing/material | Carton packing |
| Voltage | 12V |
| Internal resistance of battery | After the battery is fully charged (25°C) | <10mΩ |
| Battery capacity at different temperature | 60°C | 104% |
| 25°C | 100% |
| 0°C | 95% |
| -50°C | 86% |
| Rated capacity(Ah) at different hours | 10 hours | 100%C10 |
| 30 hours | 110%C10 |
| Storage capacity of battery | One month (25°C) | 95% |
| Three month (25°C) | 90% |
| Six month (25°C) | 88% |
| Maximum charge current | 02.5C10 (A) |
| Charge voltage limit | Voltage of equalizing charge | 14.4V/12V-25mV/C |
| Voltage of floating charge | 13.5V/12V-20mV/C |
Company InformationFoshan SNAT Energy Electrical Technology Co. Ltd is established in 2004. As a world's leading supplier for solutions for electric energy and new energy, SNAT has powerful strength and is engaged in field of solar inverters, solar inverters with built-in solar controller, solar controllers, UPS, which are used for household, telecommunication, electricity, infrastructure and industrial markets. At the same time, our company is concurrently engaged in solar panels, batteries for solar power system. We have professional technical engineer with more than 10 years technical experience to develop and design solar products.
Manufacture&Packge
FAQ:Q1:What is the warranty of your product? A:Quality warranty for 3 years; parts will be shipped free during warranty period.Q2: Can you do OEM?A:yes,we can offer the OEM service.Q3 What is your delivery time?A:Within 5 day after receive advanced payment.Q4 What minimum order do you require?A:1 pieceQ5 Why choose us?1)Prompt delivery and good after-sale services.
2)We have our own factory,the selling prices is competitive.
3)All of our products have CE certification,ISO9001:2008,RoHS.
4)80% new materials for production and superior quality.
5)professional engineer designers.
